Каталог запасных частей к технике: Lovol TD-1304. TD2S372070000 GEARBOX MAIN & AUXILIARY GEAR ASSEMBLY-2
NO-NUMBER(33)
1
2
3
4
5
6
7
8
9
10
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
41
42
43
44
45
45
46
47
48
49
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| NO-NUMBER(33) | NO-NUMBER(33) | GEARBOX MAIN & AUXILIARY GEAR ASSEMBLY | |
| 1 | NO-NUMBER(34) | MIDDLE SHAFT END COVER | |
| 2 | NO-NUMBER(35) | LOW CARTON STEEL WIRE | |
| 3 | NO-NUMBER(36) | STANDARD SPRING WASHER | |
| 4 | NO-NUMBER(37) | BOLT | |
| 5 | NO-NUMBER(38) | RETAINER RING | |
| 6 | NO-NUMBER(39) | TAPERED ROLLER BEARING | |
| 7 | NO-NUMBER(40) | ADJUSTING WASHER | |
| 8 | NO-NUMBER(41) | MIDDLE SHAFT THRUST RING | |
| 9 | NO-NUMBER(43) | SLEEVE | |
| 10 | NO-NUMBER(44) | ROLLER NEEDLE BEARING | |
| 11 | NO-NUMBER(45) | I DRIVEN GEAR | |
| 12 | NO-NUMBER(42) | BEARING SPACING SLEEVE | |
| 13 | NO-NUMBER(46) | SYNCHRONIZER ASSEMBLY | |
| 14 | NO-NUMBER(47) | DRIVEN GEAR | |
| 15 | NO-NUMBER(48) | DRIVEN GEAR | |
| 16 | NO-NUMBER(49) | DRIVEN GEAR | |
| 17 | NO-NUMBER(50) | SPACER BUSH | |
| 18 | NO-NUMBER(51) | TAPERED ROLLER BEARING | |
| 19 | NO-NUMBER(52) | MIDDLE SHAFT | |
| 20 | NO-NUMBER(53) | NEEDLE | |
| 21 | NO-NUMBER(54) | REVERSE DRIVEN GEAR SEAT | |
| 22 | NO-NUMBER(55) | REVERSE DRIVEN GEAR | |
| 23 | NO-NUMBER(56) | GEAR | |
| 24 | NO-NUMBER(57) | ROLLER NEEDLE BEARING | |
| 25 | NO-NUMBER(58) | THRUST RETAINER RING | |
| 26 | NO-NUMBER(59) | THRUST RETAINER RING | |
| 27 | NO-NUMBER(60) | THRUST RETAINER RING | |
| 28 | NO-NUMBER(61) | THRUST RETAINER RING | |
| 29 | NO-NUMBER(62) | THRUST RETAINER RING | |
| 30 | NO-NUMBER(63) | THRUST RETAINER RING | |
| 31 | NO-NUMBER(64) | THRUST RETAINER RING | |
| 32 | NO-NUMBER(65) | THRUST RETAINER RING | |
| 33 | NO-NUMBER(66) | THRUST RING | |
| 34 | NO-NUMBER(67) | SELF-ALIGNING BALL BEARING | |
| 35 | NO-NUMBER(68) | OUTPUT SHAFT | |
| 36 | NO-NUMBER(69) | PLUG PIECE | |
| 37 | NO-NUMBER(70) | IDLER SHAFT SPACER BUSH | |
| 38 | NO-NUMBER(71) | IDLER SHAFT SPACER BUSH | |
| 39 | NO-NUMBER(72) | IDLER SHAFT SPACER BUSH | |
| 40 | NO-NUMBER(73) | IDLER SHAFT SPACER BUSH | |
| 41 | NO-NUMBER(74) | RETAINER RING | |
| 42 | NO-NUMBER(75) | IDLER SHAFT | |
| 43 | NO-NUMBER(76) | IDLER | |
| 44 | NO-NUMBER(77) | REVERSE SHIFT COLLAR | |
| 45 | NO-NUMBER(78) | NEEDLE AND CARRIER COMBINATION | |
| 46 | NO-NUMBER(79) | NEEDLE SPACER BUSH | |
| 47 | NO-NUMBER(81) | IDLER 1 | |
| 48 | NO-NUMBER(80) | ADJUSTING WASHER | |
| 49 | NO-NUMBER(82) | ADJUSTING WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
