Каталог запасных частей к технике: Lovol TD-1304. TD2S372070000 GEARBOX MAIN & AUXILIARY GEAR ASSEMBLY-1

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
NO-NUMBER
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Позиция на иллюстрации Заводской номер детали Название детали
NO-NUMBER NO-NUMBER GEARBOX MAIN & AUXILIARY GEAR ASSEMBLY
1 NO-NUMBER(3) PTO FRONT SHAFT
2 NO-NUMBER(2) HEXAGON BOLT
3 NO-NUMBER(4) STANDARD SPRING WASHER
4 NO-NUMBER(5) INPUT SHAFT BEARING SEAT
5 NO-NUMBER(6) SEAL RING
6 NO-NUMBER(7) ADJUSTING WASHER
7 NO-NUMBER(8) TAPERED ROLLER BEARING
8 NO-NUMBER(9) INPUT SHAFT ASSEMBLY
9 NO-NUMBER(10) SPACER BUSH OF INPUT SHAFT
10 NO-NUMBER(11) DRIVING GEAR
11 NO-NUMBER(12) DRIVING GEAR
12 NO-NUMBER(13) ROLLER NEEDLE BEARING
13 NO-NUMBER(14) SLEEVE
14 NO-NUMBER(15) SYNCHRONIZER ASSEMBLY
15 NO-NUMBER(16) OIL PLUG ASSEMBLY
16 NO-NUMBER(17) TAPERED ROLLER BEARING
17 NO-NUMBER(18) CIRCLIPS FOR HOLE
18 NO-NUMBER(19) AUXILIARY GEARSHIFT DRIVING GEAR SHAFT
19 NO-NUMBER(20) COLUMN ROLLER BEARING
20 NO-NUMBER(21) CIRCLIP FOR SHAFT
21 NO-NUMBER(22) CIRCLIP FOR SHAFT
22 NO-NUMBER(23) AUXILIARY LOW DRIVING GEAR
23 NO-NUMBER(24) SPACER BUSH
24 NO-NUMBER(25) TAPERED ROLLER BEARING
25 NO-NUMBER(26) BEARING PRESSURE COVER
26 NO-NUMBER(27) STANDARD SPRING WASHER
27 NO-NUMBER(28) HEXAGON BOLT
28 NO-NUMBER(29) PTO SHAFT CONNECTING SLEEVE
29 NO-NUMBER(30) AUXILIARY GEARSHIFT DRIVING GEAR SHAFT SPACER
30 NO-NUMBER(31) HEXAGON BOLT
31 NO-NUMBER(32) LOCATING PLATE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
