Каталог запасных частей к технике: Lovol TD-1304. TC05421020000 TRANSFER CASE HOUSING ASSEMBLY-2

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
TC05421020000(2)
TC05421020001(2)
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
Позиция на иллюстрации Заводской номер детали Название детали
TC05421020000(2) TC05421020000(2) TRANSFER CASE HOUSING ASSEMBLY
TC05421020001(2) TC05421020001(2) TRANSFER CASE BODY ASSEMBLY
1 GBT5783-M10X25-8.8-A3L Hexagon head bolt
2 GBT93-10-A3L Standard Spring Washer
3 FT804.42.112 REAR COVER
4 GBT276-6306 Deep-grooved ball bearing
5 GBT894.1-38 Circlip For Shaft
6 FT804.42.115 Mesh Gear Seat
7 FT804.42.114 SHIFT COLLAR
8 TC05421020002a TRANSFER CASE BODY
9 GBT2878.4-M18-PLEH-A3L-NBR PLUG
10 TF1004.421.1-07 MIDDLE GEAR SHAFT
11 GBT85-M10X25-33H SCREW
12 GBT6170-M10-8-A3L Hexagon Nut, Style 1
13 GBT283-NJ2206E COLUMN ROLLER BEARING
14 GBT893.1-62 Circlips For Hole
15 TF1004.421.1-05a MIDDLE GEAR
16 TC05421020004 TRANSFER CASE ROCKER
17 GBT3452.1-17.0X1.80G Rubber O-Seal Ring
18 TC05421020003 TRANSFER CASE SIDE COVER
19 GBT5783-M10X45-8.8-A3L Hexagon Bolt
20 TF1004.421.1-02a DRIVEN GEAR
21 FT804.42.117c GEAR BUSH
22 TF1004.421A.1-02 TRANSFER CASE GEAR SHAFT
23 TF1004.421A.1-03 SPACER BUSH
24 GBT276-6307 DEEP GROOVE BALL BEARING
25 GBT9877.1-FB35X55X8D SEAL RING
26 TH02421020006 FRONT COVER
27 GBT5783-M10X40-8.8-A3L Hexagon Bolt
28 FT800.37.139 Spring
29 GBT308-10-G100-b Steel Ball
30 FT804.42.108c FORK SHAFT
31 FT804.42.107 RELEASE FORK
32 FT800.37.194 Locking Screw
33 TF1004.421.1-08 LOW CARTON STEEL WIRE
34 TC05421020007 SCREW PLUG
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
