Каталог запасных частей к технике: Lovol TD-1304. TC05382110000 REAR AXLE CENTRAL TRANSMISSION ASSEMBLY-2

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
TF1004.382A.1
TC05382110000(2)
1
2
3
4
5
6
7
8
8
9
9
10
11
11
11
11
12
12
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
Позиция на иллюстрации Заводской номер детали Название детали
TF1004.382A.1 TF1004.382A.1 DIFFERENTIAL ASSEMBLY
TC05382110000(2) TC05382110000(2) REAR AXLE CENTRAL TRANSMISSION ASSEMBLY
1 GBT297-32217 TAPERED ROLLER BEARING
2 TF1004.382A.1-03 DIFFERENTIAL HOUSING
3 TF1004.382A.1-04 BIG TAPER GEAR
4 TF1004.382.1-04 LOCKING BOLT
5 GBT6171-M14X1.5-10-A3L HEXAGON NUT, TYPE-1
6 TF1004.382A.1-09 LOCK WASHER 1
7 TF1004.382.1-02 PLANET GEAR SHAFT THRUST BOLT
8 FT800.38.210 HALF SHAFT GEAR WASHER
9 TF1004.382A.1-02 HALF SHAFT GEAR
10 TF1004.382A.1-06 LONG PLANET SHAFT
11 TF1004.382A.1-08 PLANET GEAR WASHER
12 TF1004.382A.1-01 PLANET GEAR
13 TF1004.382A.1-07 SHORT PLANET SHAFT
14 TF1004.382A.1-10 CENTRAL RING
15 TF1004.382A.1-05 DIFFERENTIAL COVER
16 TF1004.382A.1-14 LOCK WASHER 2
17 GBT5783-M12X25-10.9-A3L HEXAGON BOLT
18 GBT297-30216 TAPERED ROLLER BEARING
19 FT800.38.200 HALF SHAFT GEAR WASHER
20 FT800.38.220 HALF SHAFT GEAR WASHER
21 FT800.38.230 HALF SHAFT GEAR WASHER
22 FT800.38.240 HALF SHAFT GEAR WASHER
23 FT800.38.250 HALF SHAFT GEAR WASHER
24 TF1004.382A.1-12 LONG SPACER BUSH
25 TF1004.382A.1-11 ROLLER NEEDLE BEARING
26 TF1004.382A.1-13 SHORT SPACER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
