Каталог запасных частей к технике: Lovol TB-604. TS04482010000K Body Harness Installation Assembly
TS04482010000K
1
1
2
3
4
5
5
6
7
7
8
8
9
9
10
11
12
13
14
15
16
17
17.1
17.2
18
19
20
21
22
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| TS04482010000K | TS04482010000K | Body Harness Installation Assembly | |
| 1 | TS04482010002K | Right Armrest Light Assembly | |
| 2 | GBT818-M3X20-4.8-A2L | Cross Screw | |
| 3 | GBT93-3-A3L | Standard Spring Washer | |
| 4 | GBT97.1-3-A3L | Flat Washer | |
| 5 | GBT5783-M6X20-8.8-A2L | Hexagon head bolt | |
| 6 | FT300.48.055 | Starting Relay | |
| 7 | GBT97.1-6-A3L | Plain washer | |
| 8 | GBT93-6-A3L | Standard Spring Washer | |
| 9 | GBT6170-M6-8-A2L | Hexagon Nut, Type-1 | |
| 10 | TS04482010001K | Body Harness Assembly | |
| 11 | GBT5783-M8X20-8.8-A2L | Hexagon flange nut | |
| 12 | GBT93-8-A3L | Standard Spring Washer | |
| 13 | GBT97.1-8-A3L | Flat Washer | |
| 14 | GBT6170-M8-8-A2L | Hexagon nut, style 1 | |
| 15 | TS04482010011 | Inserts Fixing Plate Weldment | |
| 16 | TS04482150002 | Two Gang Paddle Switch | |
| 17 | TS04482150003 | Two Locks Assembly | |
| 17.1 | TS04501010005 | Oil Tank Cover | |
| 17.2 | TB550.482.3 | Ignition Lock | |
| 18 | TB550.484.2 | Brake Light Switch | |
| 19 | TS04482010008 | Rubber Ring | |
| 20 | Q67405200 | Plastic Fastening Strip | |
| 21 | 3203505D9-L | Lock cable ties | |
| 22 | GBT97.1-5-A3L | Flat Washer | |
| 23 | GBT93-5-A3L | Standard Spring Washer | |
| 24 | GBT6170-M5-8-A2L | Hexagon Nut, Type-1 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
