Каталог запасных частей к технике: Lemken Zirkon 10/600KA. Compressed-air brake Zirkon 9 KA elektronik

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
3
4
4
5
6
7
7
7
7
8
9
9
10
11
11
12
13
13
14
14
15
16
17
18
18
18
19
19
20
20
20
21
22
23
24
24
24
25
26
27
28
29
30
30
30
30
31
32
33
34
35
36
37
38
39
39
40
42
43
44
Позиция на иллюстрации Заводской номер детали Название детали
1 301 0306 Flatheaded bolt
2 301 3212 Screw
3 301 5004 Screw
4 301 7260 Screw
5 301 7280 Screw
6 303 0932 Selflocking nut
7 303 0933 Selflocking nut
8 305 8694 Washer
9 325 1145 Hose clip
10 375 2190 Vent plug
11 375 9960 Clamp
12 377 1180 Thrust ring with O-ring
13 377 1181 Thrust ring with O-ring
14 377 1301 Hose nipple
15 377 1302 Hose nipple
16 377 1350 Plug
17 377 1400 Push-in connection
18 377 1401 Push-in connection
19 377 1409 Push-in connection
20 377 1410 Push-in connection
21 377 1440 Push-in connection
22 377 1450 Push-in connection
23 377 1460 Screwed socket
24 377 1461 Screwed socket
25 377 1472 Screwed socket
26 377 1482 Reducing fitting
27 377 1341 Test coupling
28 377 1380 Dewatering valve
29 377 2022 Brake hose
30 377 2070 Synthetic tube
31 377 2520 Hose clamp
32 377 2531 Strap
33 377 2540 Hose coupling
34 377 2541 Hose coupling
35 577 2570 Venting filter
36 577 2580 Filter
37 577 2591 Trailer brake valve
38 577 2621 Compressed-air container
39 577 2641 Membrane-cylinder
40 577 2660 2-port control valve
42 577 2680 Nonreturn valve
43 577 2690 Parking valve
44 577 2671 Quick release valve
45 477 1128 Holder braking valve
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
