Каталог запасных частей к технике: Lemken Vari-Opal X160. 661 2190 Lower link quick connection

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано Achat 9/400 KA (2004) Achat 9/500 KA (2004) Achat 9/600 KA (2004) Azurit 9 (2018) Dolomit 9 (2010) EuroDiamant 10 (2010) EuroDiamant 10 X (2010) EuroDiamant 8 (2010) EuroGranat 5 (2006) EuroGranat 6 (2006) EuroGranat 7 (2006) EurOpal 5 (2010) EurOpal 5HX (2010) EurOpal 6 (2010) EurOpal 7 (2010) EurOpal 7, EurOpal 7HX (2018) EurOpal 7X (2010) EurOpal 7X, EurOpal 7 HydriX (2018) EurOpal 8 (2010) EurOpal 9 (2010) EuroTitan 10 (2010) EuroTitan 10X (2010) FixPack (2010) Gigant 1000 (2010) Gigant 1000 Smaragd (2010) Gigant 800 (2010) Gigant 800 S (2010) Gigant 800 S Rubin (2006) Gigant 800 Smaragd (2010) Heliodor 9/600KA (2018) Heliodor 9/700KA (2018) Juwel 8M (2018) Karat 9/600 KA (2016) Kristall 9/500KA (2016) Kristall 9/600KA (2016) OptiDisc 25 (2018) Primus 10 (Часть 1) (2017) Primus 10 (Часть 2) (2017) Quarz 7/250 (2010) Quarz 7/250 F (2010) Quarz 7/300 (2010) Quarz 7/300F (2010) Quarz 7/400 (2010) Quarz 7/400F (2010) Quarz 7/400K (2010) Quarz 7/400KA (2010) Quarz 7/500K (2010) Quarz 7/500KA (2010) Quarz 7/600K (2010) Rubin 10/600 KUA (2018) Rubin 10/700 KUA (2018) Rubin 12/400 KUA (A) (2018) Rubin 12/500 KUA (A) (2018) Rubin 12/600 KUA (A) (2018) Rubin 12/700 KUA (2018) Rubin 9/300 U (2004) Rubin 9/400 U (2004) Saphir 7/300 (2010) Saphir 7/400 (2010) Smaragd 7/260 (2010) Smaragd 7/300 (2010) Smaragd 9/300 (2010) Smaragd 9/400 (2010) Smaragd 9/400 (2016) Smaragd 9/400 K (2016) Smaragd 9/400K (2010) Smaragd 9/450K (2010) Smaragd 9/500 K (2016) Smaragd 9/500K (2004) Smaragd 9/600 K (2016) Smaragd 9/600K (2010) Smaragd 9/600KA (2010) Solitair 10/600K (2006) Solitair 12/1000K (2007) Solitair 12/1200K (2008) Solitair 12/1200KD (2018) Solitair 12/5800SW (2018) Solitair 12/800K (2006) Solitair 12/900K (2007) Solitair 8/300 (2004) Solitair 8/300 (2014) Solitair 8/400 (2004) Solitair 9/300 (2004) Solitair 9/400 (2004) Solitair 9/400K (2004) Solitair 9/400KA (2004) Solitair 9/450K (2004) Solitair 9/450KA (2004) Solitair 9/500K (2004) Solitair 9/500KA (2009) Solitair 9/600K (2004) Solitair 9/600KA (2004) System-Kompaktor Gigant 1000 (2010) System-Kompaktor Gigant 800 (2010) System-Kompaktor K450 (2010) System-Kompaktor K450A (2010) System-Kompaktor K500 (2010) System-Kompaktor K500A (2010) System-Kompaktor K600 (2010) System-Kompaktor K600A (2010) System-Kompaktor S300 (2010) System-Kompaktor S400 (2010) System-Korund 300 L (2010) System-Korund 450 L (2010) System-Korund 600 L (2010) System-Korund 750 K (750 L) (2010) System-Korund 900 K (2010) System-Korund 900 L (2010) Thorit 8/300 (2005) Thorit 8/300 Combi-Liner (2004) Thorit 8/400 (2010) Thorit 8/400 Combi-Liner (2004) Thorit 9/400 K (2004) Thorit 9/400 KA (2003) Thorit 9/450 K (2004) Thorit 9/500 K (2004) Thorit 9/500 KA (2003) Thorit 9/600 K (2004) Thorit 9/600 KA (2003) Topas 140-A (2010) Vari-Diamant 10 (2004) Vari-Diamant 10X (2004) Vari-Opal 100 (2014) Vari-Opal 100HX (2014) Vari-Opal 100X (2014) Vari-Opal 160 (2014) Vari-Opal X160 (2014) Vari-Titan 10 (2010) Vari-Turmalin 10 (2005) Vari-Turmalin 10X (2005) Variopack 110DP70 (2010) Variopack 110DP90 (2010) Variopack 110EP90 (2010) Variopack 110FEPK700 (2010) Variopack 80DP70 (2010) Variopack S 110DP70 (2010) VariOpal 5 (2010) VariOpal 7 (2010) VariOpal 7X (2010) VariOpal 8 (2010) VariOpal 8X (2010) VariOpal 9 (2010) VariOpal 9X (2010) Zirkon 10/300 (2010) Zirkon 10/400 (2010) Zirkon 10/400K (2010) Zirkon 10/450 (2010) Zirkon 10/450K (2010) Zirkon 10/450KA (2010) Zirkon 10/500K (2010) Zirkon 10/500KA (2010) Zirkon 10/600KA (2010) Zirkon 7/250 (2010) Zirkon 7/300 (2010) Zirkon 7/400 (2010) Zirkon 9/300 (2010) Zirkon 9/400 (2010) Zirkon 9/600K "B" (2010)

Схема > Не выбрано 313 7911 Contents 321 9121 Tool set 633 7225 Turnover mechanism 633 7226 Turnover mechanism 633 7230 Turnover mechanism 633 7231 Turnover mechanism 633 7431 Locking device 602 8200 Basic frame 602 8201 Basic frame 602 8205 Basic frame 602 8206 Basic frame 602 8230 Frame extension 602 8232 Frame extension 313 7911 Top link pin with chain 313 7921 Top link pin with chain 634 1642 Width adjuster 634 3155 Adjustment centre 629 2510 Stand 661 1215 Three point connection 661 1221 Three point connection 661 1240 Three point connection 661 1350 Lower link connection 661 1354 Lower link connection 661 1372 Lower link connection 661 2140 Three point connection 661 2141 Three point connection 661 2190 Lower link quick connection 661 4127 Spacer block 321 9212 Pointer 321 9217 Pointer 321 9218 Pointer 321 9219 Pointer 602 2409 Beam guiding 602 2410 Beam guiding 602 2411 Beam guiding 602 2412 Beam guiding 549 8846 Wheel 6/100/140 D16 549 8847 Wheel 6/100/140 D16 549 8848 Wheel 6/100/140 D16 549 8849 Wheel 5/94/140 D14 549 8850 Wheel 6/161/205 D18 549 8886 Bearing 549 8893 Bearing 549 8894 Bearing 550 8863 Wheel 6/161/205 D18 648 7710 Depth wheel, lateral 648 7715 Depth wheel, lateral 648 7721 Depth wheel, lateral 649 1290 Uni-wheel 649 1295 Uni-wheel 649 1304 Uni-wheel 649 1315 Uni-wheel 649 1319 Uni-wheel 649 1324 Uni-wheel 649 1332 Uni-wheel 10.0/80-12 373 4150 Extension cable 670 1151 Carrier for light 670 1200 Carrier for light 670 2012 Warning boards with lighting 575 2430 Ram 575 2440 Memory ram 575 2443 Memory ram 575 2444 Memory ram 575 2445 Memory ram 575 2472 Change over ram 575 2475 Switch over ram for VUP 575 2476 Switch over ram for VUP 575 9905 Conversion-set 675 1316 HY-assembly attachment arm 675 1320 HY-assembly attachment arm 675 3322 HY-assembly turnover device 675 3323 HY-turnover device for VUP 675 3324 HY-turnover device for VUP 675 3569 Width adjuster 675 3571 HY-width adjuster Memory 675 3572 Width adjuster 675 3575 HY-width adjuster Memory-VUP 675 3576 Width adjuster 675 3581 Width adjuster 675 3582 HY-width adjuster Memory 675 3586 HY-width adjuster Memory 675 3588 HY-width adjuster Memory 675 3590 Memory connection M+S to P+T 675 3591 Memory connection M+S to P+T 663 8472 Skim stalk 663 8474 Skim stalk 663 8730 Skim stalk 626 5670 Lock 626 8156 Trip device+double springs 626 8169 Trip device with roller 464 3842 Leg 464 3852 Leg 464 4000 Leg 699 6000 Bolts for leg 657 7818 Trip disc-coulter 657 7819 Trip disc-coulter 657 7820 Trip disc-coulter 657 7821 Trip disc-coulter 657 7832 Trip disc-coulter 657 7833 Trip disc-coulter 657 9332 Disc arm 657 9333 Disc arm 663 7840 Disc stalk 622 2603 Attachment arm

1

2

3

4

5

6

7

7

8

9

10

11

12

Позиция на иллюстрации	Заводской номер детали		Название детали
1	301 3868		Bolt
2	301 6425		Bolt
3	303 0935		Selflocking nut
4	309 3337		Expansion bush
5	309 6038		Expansion bush
6	313 8646		Pin
7	315 9710		Rivet
8	329 8106		Spring
9	329 8495		Spring
10	461 7925		Drawbar
11	461 8179		Hook
12	461 9891		Stop

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
