Каталог запасных частей к технике: Lemken Vari-Diamant 10X. Hydraulic assembly X-HY 7SG-1000 AD
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
AGCO
Amity
CASE IH
DongFeng
Fortschritt
Foton
Franz Kleine
Gaspardo
Great Plains
KRONE
KUHN
Lemken
Lovol
MacDon
Massey Ferguson
New Holland
TIGARBO
Vaderstad
Versatile
Wirax
Агро
Агротехмаш
Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш»)
БЭМЗ
ВгТЗ
Воронежсельмаш
ВТЗ
Гомсельмаш
ДКЗ
ЗАО "Техника-сервис"
ЗиД
КЗК
Кировец-Ландтехник
Клевер
Красная Звезда
Лидагропроммаш
Лидсельмаш
ЛТЗ
Машстройхолдинг
Минитракторы
Мордовагромаш
МТЗ
Навигатор-Новое машиностроение
Нефтекамский автозавод
ПТЗ
Ремком
РСМ
Сибсельмаш
ТеКЗ
ТКЗ
ХЗТСШ
ХТЗ
ЮМЗ
Модель
Не выбрано
Achat 9/400 KA (2004)
Achat 9/500 KA (2004)
Achat 9/600 KA (2004)
Azurit 9 (2018)
Dolomit 9 (2010)
EuroDiamant 10 (2010)
EuroDiamant 10 X (2010)
EuroDiamant 8 (2010)
EuroGranat 5 (2006)
EuroGranat 6 (2006)
EuroGranat 7 (2006)
EurOpal 5 (2010)
EurOpal 5HX (2010)
EurOpal 6 (2010)
EurOpal 7 (2010)
EurOpal 7, EurOpal 7HX (2018)
EurOpal 7X (2010)
EurOpal 7X, EurOpal 7 HydriX (2018)
EurOpal 8 (2010)
EurOpal 9 (2010)
EuroTitan 10 (2010)
EuroTitan 10X (2010)
FixPack (2010)
Gigant 1000 (2010)
Gigant 1000 Smaragd (2010)
Gigant 800 (2010)
Gigant 800 S (2010)
Gigant 800 S Rubin (2006)
Gigant 800 Smaragd (2010)
Heliodor 9/600KA (2018)
Heliodor 9/700KA (2018)
Juwel 8M (2018)
Karat 9/600 KA (2016)
Kristall 9/500KA (2016)
Kristall 9/600KA (2016)
OptiDisc 25 (2018)
Primus 10 (Часть 1) (2017)
Primus 10 (Часть 2) (2017)
Quarz 7/250 (2010)
Quarz 7/250 F (2010)
Quarz 7/300 (2010)
Quarz 7/300F (2010)
Quarz 7/400 (2010)
Quarz 7/400F (2010)
Quarz 7/400K (2010)
Quarz 7/400KA (2010)
Quarz 7/500K (2010)
Quarz 7/500KA (2010)
Quarz 7/600K (2010)
Rubin 10/600 KUA (2018)
Rubin 10/700 KUA (2018)
Rubin 12/400 KUA (A) (2018)
Rubin 12/500 KUA (A) (2018)
Rubin 12/600 KUA (A) (2018)
Rubin 12/700 KUA (2018)
Rubin 9/300 U (2004)
Rubin 9/400 U (2004)
Saphir 7/300 (2010)
Saphir 7/400 (2010)
Smaragd 7/260 (2010)
Smaragd 7/300 (2010)
Smaragd 9/300 (2010)
Smaragd 9/400 (2010)
Smaragd 9/400 (2016)
Smaragd 9/400 K (2016)
Smaragd 9/400K (2010)
Smaragd 9/450K (2010)
Smaragd 9/500 K (2016)
Smaragd 9/500K (2004)
Smaragd 9/600 K (2016)
Smaragd 9/600K (2010)
Smaragd 9/600KA (2010)
Solitair 10/600K (2006)
Solitair 12/1000K (2007)
Solitair 12/1200K (2008)
Solitair 12/1200KD (2018)
Solitair 12/5800SW (2018)
Solitair 12/800K (2006)
Solitair 12/900K (2007)
Solitair 8/300 (2004)
Solitair 8/300 (2014)
Solitair 8/400 (2004)
Solitair 9/300 (2004)
Solitair 9/400 (2004)
Solitair 9/400K (2004)
Solitair 9/400KA (2004)
Solitair 9/450K (2004)
Solitair 9/450KA (2004)
Solitair 9/500K (2004)
Solitair 9/500KA (2009)
Solitair 9/600K (2004)
Solitair 9/600KA (2004)
System-Kompaktor Gigant 1000 (2010)
System-Kompaktor Gigant 800 (2010)
System-Kompaktor K450 (2010)
System-Kompaktor K450A (2010)
System-Kompaktor K500 (2010)
System-Kompaktor K500A (2010)
System-Kompaktor K600 (2010)
System-Kompaktor K600A (2010)
System-Kompaktor S300 (2010)
System-Kompaktor S400 (2010)
System-Korund 300 L (2010)
System-Korund 450 L (2010)
System-Korund 600 L (2010)
System-Korund 750 K (750 L) (2010)
System-Korund 900 K (2010)
System-Korund 900 L (2010)
Thorit 8/300 (2005)
Thorit 8/300 Combi-Liner (2004)
Thorit 8/400 (2010)
Thorit 8/400 Combi-Liner (2004)
Thorit 9/400 K (2004)
Thorit 9/400 KA (2003)
Thorit 9/450 K (2004)
Thorit 9/500 K (2004)
Thorit 9/500 KA (2003)
Thorit 9/600 K (2004)
Thorit 9/600 KA (2003)
Topas 140-A (2010)
Vari-Diamant 10 (2004)
Vari-Diamant 10X (2004)
Vari-Opal 100 (2014)
Vari-Opal 100HX (2014)
Vari-Opal 100X (2014)
Vari-Opal 160 (2014)
Vari-Opal X160 (2014)
Vari-Titan 10 (2010)
Vari-Turmalin 10 (2005)
Vari-Turmalin 10X (2005)
Variopack 110DP70 (2010)
Variopack 110DP90 (2010)
Variopack 110EP90 (2010)
Variopack 110FEPK700 (2010)
Variopack 80DP70 (2010)
Variopack S 110DP70 (2010)
VariOpal 5 (2010)
VariOpal 7 (2010)
VariOpal 7X (2010)
VariOpal 8 (2010)
VariOpal 8X (2010)
VariOpal 9 (2010)
VariOpal 9X (2010)
Zirkon 10/300 (2010)
Zirkon 10/400 (2010)
Zirkon 10/400K (2010)
Zirkon 10/450 (2010)
Zirkon 10/450K (2010)
Zirkon 10/450KA (2010)
Zirkon 10/500K (2010)
Zirkon 10/500KA (2010)
Zirkon 10/600KA (2010)
Zirkon 7/250 (2010)
Zirkon 7/300 (2010)
Zirkon 7/400 (2010)
Zirkon 9/300 (2010)
Zirkon 9/400 (2010)
Zirkon 9/600K "B" (2010)
Схема
>
Не выбрано
Vari-Diamant 10 X
Top link pin with chain K700 D40/44,5x228
Top link pin with chain KAT3GK700 31,7x228
Top link pin with chain KAT3G 31,7x213
Headstock D100 Diamant 10
Lower link connection AD10 D68 L2 Z3
Lower link connection AD10 D68 L3 Z3
Lower link connection AD10 D68 L3 Z4
Lower link connection AD10 D68 L1100 Z4 K700
Lower link connection D68/68 L3 Z3/91
Headstock Drehwerk Diamant 10 On-Land
Headstock Drehwerk Diamant 10
Tool set Vari-Diamant/Diamant S
Turnbuckle TR30x3/730/520 MVS
Stabilizer 5-100 AD10 140x2010
Stabilizer 6-100 AD10 140x3010
Stabilizer 7-100 AD10 140x4010
Stabilizer 5-100 AD10 140x1912
Stabilizer 6-100 AD10 140x2912
Stabilizer 7-100 AD10 140x3912
Stabilizer 5-120 AD10 140x....
Stabilizer joint VT10
Stabilizer joint AD10
Pointer Vari-Diamant 10
Pointer Vari-Diamant 10 s.Uberlasts
Rod V-D10X R5K-V3K-H2K
Rod V-D10X R5K-V3K-H3K
Rod V-D10X R6K-V4K-H2K
Rod V-D10X R6K-V4K-H3K
Rod V-D10X R7K-V5K-H2K
Rod V-D10X R7K-V5K-H3K
Rod Anbauteil VO 9/9X-4/5/6-120
Rod Vari-Diamant 10
Rod Vari-Diamant 10
Rod Vari-Diamant 10
Rod Vari-Diamant 10 -120
Basic frame VariDiamant 10 5-100
Basic frame VariDiamant 10 6-100
Basic frame VariDiamant 10 7-100
Basic frame VariDiamant 10 5-120
Frame extension VO 9-100
Rod Vari-Opal 9/9X-5-100 ohne Rad
Rod Anbauteil VO 9/9X-4/5/6-100
Bearing V60-6/160/205 D18
Bearing D35x622 6/205 MONROC
Wheel 6/161/205 D18 11.5/80-15.3 10PR AW
Wheel 6/161/205 D18 38x20,00x16,1 STG 8PR LO
Wheel 6/161/205 D18 38x20,00x16,1 STG 8PR Li
Wheel 6/161/205 D18 NOKIA 500/60-15.5 ELS ET-0
Depth wheel Vari-Diamant 10
Swinging depth wheel D50x160 Diamant10 11,5/80-15,3
Trip disc-coulter X140-X160 RE 500 G
Trip disc-coulter X140-X160 LI 500 G
Trip disc-coulter X140-X160 RE 500 Z
Trip disc-coulter X140-X160 LI 500 Z
Disc arm D500-G Z50
Disc arm D500-Z Z50
Extension cable 7-polig 2,5m
Lighting equipment Pflug
Lighting equipment BLA-1 PF/UNI 33,7x1580
Trip device with roller 80x35-V
Trip device Rolle-HY-170-80.35-D14
Bolts for leg Dural
Leg 80x35/V
Disc stalk D40/80 Z50
Skim stalk DE-D45 H750-800
Skim stalk S1 50x30x371/G 80x35
Attachment arm E2V
Bracket Diamant 10
Hose-assembly 2x5900,2x4600,1x7500 MSS
Hose-assembly 2x4600,2x6900,1x8500 MSS
Hose-assembly 2x4600,2x7900,1x9500 MSS
Hose-assembly 2x4600,2x8500,1x10500 MSS
Hose-assembly 2x4600,1x7500 MSS
Hose-assembly 2x4600,1x8500 MSS
Hose-assembly 2x4600,1x9500 MSS
Hose-assembly 2x4600,1x10500 MSS
Adapter-inner thread K700
Hydraulic assembly X-HY 1SA-1000
Holder Diamant 10 X-HY
Hydraulic assembly X-HY 1SA-1000
Hydraulic assembly X-HY 5SG-1000 AD
Hydraulic assembly X-HY 6SG-1000 AD
Hydraulic assembly X-HY 7SG-1000 AD
Hydraulic assembly X-HY 5SG-1200 AD
HY-assembly attachment arm PA-Vari-Diamant
HY-assembly attachment arm PA-Diamant 10
HY-assembly attachment arm PA-Diamant 10 OF
HY-front furrow adjustment HY V-AD-10 5-100
HY-front furrow adjustment HY V-AD-10 6-100
HY-front furrow adjustment HY V-AD-10 7-100
HY-front furrow adjustment HY V-AD-10 8-100
HY-assembly turnover device ET78/97-500 Diamant 10
HY-assembly Onland DZ80-320 Diamant 10
HY-assembly depth wheel Vari-Diamant 10
HY-assembly depth wheel Diamant ED10 5-100
HY-assembly depth wheel 6-100 ED10
HY-assembly depth wheel 7-100 ED10
HY-assembly depth wheel 8-100 ED10
Width adjuster DZ80-200 5-100 Diamant 10
Width adjuster DZ80-200 6-10 Diamant 10
Width adjuster DZ80-200 7-100 Diamant 10
Width adjuster DZ80-160 5-100 Diamant 10
Width adjuster DZ80-160 6-100 Diamant 10
Width adjuster DZ80-160 7-100 Diamant 10
Stalk bracket Vari-Diamant 10X
Stalk bracket Vari-Diamant 10X m.seitl.Uberl
Stalk bracket Vari-Opal 9 X
1
3
4
5
11
11
13
14
16
17
18
19
20
21
22
23
23
24
25
25
26
26
28
29
30
31
32
33
34
35
36
38
39
42
43
45
46
47
48
49
Позиция на иллюстрации
Заводской номер детали
Название детали
1
301 0302
Flatheaded bolt
3
301 4608
Bolt
4
301 7260
Screw
5
303 0936
Selflocking nut
11
375 2124
Cap, white
13
375 2718
SVK-socket
14
375 4020
Nipple
16
375 4040
Nipple
17
375 4120
Nipple
18
375 4220
Angle union
19
375 4484
T-union
20
375 4494
T-adjustable T-union
21
375 4500
Adjustable angle union
22
375 4503
Adjustable angle union
23
375 4553
L-adjustable T-union
24
375 4653
Reduction joint
25
375 5120
Cutting ring
26
375 5320
Union nut
28
375 9951
Weld on plate
29
375 9961
Clamp
30
475 3035
High-pressure hose
31
475 3009
High-pressure hose
32
475 3010
High-pressure hose
33
475 3011
High-pressure hose
34
475 2633
High-pressure hose
35
475 4373
Holder
36
475 9969
Tube
38
475 9973
Tube
39
575 2523
Hydraulic ram
42
575 9041
Block for HydriX
43
575 9042
Block for HydriX
45
475 9971
Tube
46
301 7803
U-bolt
47
303 0935
Selflocking nut
48
475 4385
Holder
49
475 9970
Tube
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
