Каталог запасных частей к технике: Lemken Thorit 9/600 K. Thorit 9/600 K
1
1
1
1
1
1
1
1
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
6
6
6
6
6
8
8
8
8
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 617 8266 | Lateral part | |
| 1 | 617 8267 | Lateral part | |
| 1 | 617 8269 | Center section | |
| 1 | 640 5242 | Headstock | |
| 1 | 647 2520 | Depth wheel | |
| 1 | 647 7476 | Wheel bracket | |
| 1 | 647 7477 | Wheel bracket | |
| 1 | 617 8147 | Hydraulic locking device | |
| 2 | 661 1386 | Lower link connection | |
| 2 | 661 1388 | Lower link connection | |
| 2 | 661 1387 | Lower link connection | |
| 2 | 661 1385 | Lower link connection | |
| 3 | 622 6739 | Trapeze packer roller | |
| 3 | 622 6821 | Knife roller | |
| 3 | 622 6744 | Packer roller, short scraper | |
| 3 | 622 6752 | Trapeze packer roller | |
| 3 | 622 6760 | Trapeze packer roller | |
| 3 | 622 6766 | Trapeze disc roller | |
| 3 | 622 6810 | Knife roller | |
| 3 | 622 6811 | Knife roller | |
| 3 | 622 6820 | Knife roller | |
| 3 | 622 6858 | Double roller | |
| 3 | 622 6859 | Double roller | |
| 3 | 622 6873 | Rubber ring roller | |
| 3 | 622 0184 | Holder | |
| 3 | 622 6707 | Double roller | |
| 3 | 617 8188 | Adapter-inner thread | |
| 3 | 622 6345 | Packer roller | |
| 3 | 622 6602 | Tube bar roller | |
| 3 | 622 6608 | Tube bar roller | |
| 3 | 622 6609 | Tube bar roller | |
| 3 | 622 6628 | Tube bar roller | |
| 3 | 622 6629 | Tube bar roller | |
| 3 | 622 6688 | Double roller | |
| 3 | 622 6689 | Double roller | |
| 3 | 622 6706 | Double roller | |
| 4 | 617 7147 | Carrier | |
| 4 | 657 2444 | Pair of hollow discs | |
| 4 | 657 2426 | Bracket for outer disc | |
| 4 | 657 2421 | Hollow disc | |
| 4 | 657 2420 | Hollow disc | |
| 4 | 657 2418 | Pair of hollow discs | |
| 4 | 622 6386 | Levelling type harrow | |
| 4 | 617 7158 | Frame for hollow discs | |
| 4 | 617 7145 | Carrier | |
| 4 | 617 7144 | Carrier | |
| 4 | 617 7143 | Carrier | |
| 4 | 617 7142 | Carrier | |
| 4 | 617 7141 | Carrier | |
| 4 | 617 7140 | Carrier | |
| 4 | 617 7116 | Balance bar | |
| 4 | 617 7146 | Carrier | |
| 5 | 699 0701 | Tools | |
| 5 | 627 5726 | Trip device | |
| 5 | 627 5695 | Trip device | |
| 6 | 570 2053 | Set of cables | |
| 6 | 670 2020 | Lighting equipment with boards | |
| 6 | 670 2047 | Cable set with carrier | |
| 6 | 670 2051 | Carrier for light extension | |
| 6 | 670 2054 | Carrier for light extension | |
| 8 | 575 6601 | Adapter-inner thread | |
| 8 | 675 7040 | Hydraulic assembly | |
| 8 | 675 7042 | HY-assembly unlocking device | |
| 8 | 675 7043 | Hydraulic assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
