Каталог запасных частей к технике: Lemken Solitair 9/500KA. Lighting equipment, rear Solitair 9 K

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано Achat 9/400 KA (2004) Achat 9/500 KA (2004) Achat 9/600 KA (2004) Azurit 9 (2018) Dolomit 9 (2010) EuroDiamant 10 (2010) EuroDiamant 10 X (2010) EuroDiamant 8 (2010) EuroGranat 5 (2006) EuroGranat 6 (2006) EuroGranat 7 (2006) EurOpal 5 (2010) EurOpal 5HX (2010) EurOpal 6 (2010) EurOpal 7 (2010) EurOpal 7, EurOpal 7HX (2018) EurOpal 7X (2010) EurOpal 7X, EurOpal 7 HydriX (2018) EurOpal 8 (2010) EurOpal 9 (2010) EuroTitan 10 (2010) EuroTitan 10X (2010) FixPack (2010) Gigant 1000 (2010) Gigant 1000 Smaragd (2010) Gigant 800 (2010) Gigant 800 S (2010) Gigant 800 S Rubin (2006) Gigant 800 Smaragd (2010) Heliodor 9/600KA (2018) Heliodor 9/700KA (2018) Juwel 8M (2018) Karat 9/600 KA (2016) Kristall 9/500KA (2016) Kristall 9/600KA (2016) OptiDisc 25 (2018) Primus 10 (Часть 1) (2017) Primus 10 (Часть 2) (2017) Quarz 7/250 (2010) Quarz 7/250 F (2010) Quarz 7/300 (2010) Quarz 7/300F (2010) Quarz 7/400 (2010) Quarz 7/400F (2010) Quarz 7/400K (2010) Quarz 7/400KA (2010) Quarz 7/500K (2010) Quarz 7/500KA (2010) Quarz 7/600K (2010) Rubin 10/600 KUA (2018) Rubin 10/700 KUA (2018) Rubin 12/400 KUA (A) (2018) Rubin 12/500 KUA (A) (2018) Rubin 12/600 KUA (A) (2018) Rubin 12/700 KUA (2018) Rubin 9/300 U (2004) Rubin 9/400 U (2004) Saphir 7/300 (2010) Saphir 7/400 (2010) Smaragd 7/260 (2010) Smaragd 7/300 (2010) Smaragd 9/300 (2010) Smaragd 9/400 (2010) Smaragd 9/400 (2016) Smaragd 9/400 K (2016) Smaragd 9/400K (2010) Smaragd 9/450K (2010) Smaragd 9/500 K (2016) Smaragd 9/500K (2004) Smaragd 9/600 K (2016) Smaragd 9/600K (2010) Smaragd 9/600KA (2010) Solitair 10/600K (2006) Solitair 12/1000K (2007) Solitair 12/1200K (2008) Solitair 12/1200KD (2018) Solitair 12/5800SW (2018) Solitair 12/800K (2006) Solitair 12/900K (2007) Solitair 8/300 (2004) Solitair 8/300 (2014) Solitair 8/400 (2004) Solitair 9/300 (2004) Solitair 9/400 (2004) Solitair 9/400K (2004) Solitair 9/400KA (2004) Solitair 9/450K (2004) Solitair 9/450KA (2004) Solitair 9/500K (2004) Solitair 9/500KA (2009) Solitair 9/600K (2004) Solitair 9/600KA (2004) System-Kompaktor Gigant 1000 (2010) System-Kompaktor Gigant 800 (2010) System-Kompaktor K450 (2010) System-Kompaktor K450A (2010) System-Kompaktor K500 (2010) System-Kompaktor K500A (2010) System-Kompaktor K600 (2010) System-Kompaktor K600A (2010) System-Kompaktor S300 (2010) System-Kompaktor S400 (2010) System-Korund 300 L (2010) System-Korund 450 L (2010) System-Korund 600 L (2010) System-Korund 750 K (750 L) (2010) System-Korund 900 K (2010) System-Korund 900 L (2010) Thorit 8/300 (2005) Thorit 8/300 Combi-Liner (2004) Thorit 8/400 (2010) Thorit 8/400 Combi-Liner (2004) Thorit 9/400 K (2004) Thorit 9/400 KA (2003) Thorit 9/450 K (2004) Thorit 9/500 K (2004) Thorit 9/500 KA (2003) Thorit 9/600 K (2004) Thorit 9/600 KA (2003) Topas 140-A (2010) Vari-Diamant 10 (2004) Vari-Diamant 10X (2004) Vari-Opal 100 (2014) Vari-Opal 100HX (2014) Vari-Opal 100X (2014) Vari-Opal 160 (2014) Vari-Opal X160 (2014) Vari-Titan 10 (2010) Vari-Turmalin 10 (2005) Vari-Turmalin 10X (2005) Variopack 110DP70 (2010) Variopack 110DP90 (2010) Variopack 110EP90 (2010) Variopack 110FEPK700 (2010) Variopack 80DP70 (2010) Variopack S 110DP70 (2010) VariOpal 5 (2010) VariOpal 7 (2010) VariOpal 7X (2010) VariOpal 8 (2010) VariOpal 8X (2010) VariOpal 9 (2010) VariOpal 9X (2010) Zirkon 10/300 (2010) Zirkon 10/400 (2010) Zirkon 10/400K (2010) Zirkon 10/450 (2010) Zirkon 10/450K (2010) Zirkon 10/450KA (2010) Zirkon 10/500K (2010) Zirkon 10/500KA (2010) Zirkon 10/600KA (2010) Zirkon 7/250 (2010) Zirkon 7/300 (2010) Zirkon 7/400 (2010) Zirkon 9/300 (2010) Zirkon 9/400 (2010) Zirkon 9/600K "B" (2010)

Схема > Не выбрано Solitair 9/500 KA > 263550 Electric drive Solitair Support Solitair Dosage, top part K 4-A Dosage, lower part K 4-A Seeding mechanism 4-A E 6/L 45GRD Solitair Hopper 1850l (170cm) Hopper 2300 Liter Tank/Hopper 1850l (160cm) Tankdeckel/Cover 1100l-1850l (170cm) Cover 2300l Tank/Cover 1850l (160cm) Dosage 4-Auslaufe C Dosierung/Dosage K 4xA Solitair Flexible hose D25x1100 1xD30 Flexible hose D25x450 Holder for distributor 90x90 325x295 A D77 Holder for distributor 90x90 282x70 I D77 Emptying unit for hopper 10B-M80x4 Emptying unit for hopper 7/8B-M64x4 Emptying unit for hopper 9B-M72x4 Tramline mechanism 1-F Tramline mechanism 2-F Distributor 8B Distributor 9B Distributor 10B Supply hoses D65 2x1420 2x2320 500KA Recirculation Solitair 9 Cyclone D230-570 Solitair-KA+FW Fan Typ GST 520 Basic frame Solitair Adjustment centre 720 M Solitair DS Adjustment centre 720 M Solitair ES Adjustment centre 1010 HY Solitair KA B Adjustment centre 1010 HY Solitair KA ES+S Adjustment centre 720 HYD Solitair DS Adjustment centre 720 HYD Solitair ES Step with platform 660x975 3+1 KA Solitair Step with platform 660x975 3+1 KA Solitair f.k.Ta Step with platform 3STU.o.STR.1100-1850 Sol.K Step with platform 3STU.o.STR.2300 Sol.KA/SA Step with platform 3STU.o.STR.1100-1850 Sol.KA/SA Step with platform 4STU.m.STR.2300 Sol.KA/SA Step with platform 4STU.m.STR.1100-1850 Sol.KA/SA Step with platform 4STU.m.STR.1100-1850 Sol.S Coulter frame Solitair 9/500-K 40R-125 Coulter frame Solitair 9/500-K 34R-150 Coulter frame Solitair 9/500-K 29R-175 Coulter frame Solitair 9/500-K 40R-125 Coulter frame Solitair 9/500-K 34R-150 Coulter frame Solitair 9/500-K 29R-175 Levelling harrow S-1,00 Levelling harrow S-1,25 Levelling harrow S-1,50 Swinging arm Cover with scraper kpl. Cover with hard metal scraper kpl. Rocker arm B-250 Disc D350/70/34x3 AA Disc carrier B 45/10x475 Levelling harrow S-1,00 Levelling harrow S-1,25 Carrier STR 70x2000 Holder, short Double disc coulter + roller D350/330 B-250 Single disc coulter, long D325 RE Single disc coulter, short D325 LI Single disc coulter, short D325 RE Single disc coulter, long D325 LI Single harrow D10x960 Pre-emergency marker HS D325 VALM Pre-emergency marker lang MI-Rahmen Pre-emergency marker LEMKEN kurz MI_Rahmen Pre-emergency marker DS-Ausfuhrung Holder, long Fittings FK Solitair/Zirkon 9 Fittings Solitair-Fremdgerate Support 26,9x277 1x90 D16,25 Lighting equipment, front Solitair 9 FW Lighting equipment, rear Solitair 9 K Lighting equipment, front Solitair 9 FW Lighting equipment Solitair 9 Lighting equipment Solitair 9 Top link pin, cpl. KAT2 D25,4x140 Bearing V60-6/160/205 D18 Bearing 8/220/275 M18 80x80 Wheel 6/161/205 D18 11.5/80-15.3 10PR AW Wheel 6/161/205 D18 400-15.5 T404 -14PR RE Wheel 6/161/205 D18 400-15.5 T404 -14PR LI Wheel 8/221/575 Trelleborg 550/60-22.5 12PR/RE Wheel 8/221/575 Trelleborg 550/60-22.5 12PR/LI Deichsel Fur Fahrwerk Solitair Trailer Solitair D55 A 6/160/205 Trailer Solitair 8-Loch Lower link connection D55/P L2 Z2 Lower link connection D55/P L2 Z3 Lower link connection D55/P L3 Z2 Lower link connection D55/P L3 Z3 Carrier D55x35 6x60-200 Stand 40x20/90x90-Solitair Stand 40x20/120x120-Solitair Stand RE+LE Solitair + Saphir 7 Holder 120x120 Solitair Holder 90x90x132 40x20 Track scraper FSU-VS33 Track scraper FSU+G25 40x20 Track scraper with holder FSU-G25 120x120 Solitair Track scraper with holder FSU-G25 90x90-162 Solitair KA Track scraper with holder FSU-VS33-90x90-162 Track scraper with holder FSU-VS33-120x120 Axle for track marker D30x595 668A Track marker FWK Solitair 500 D380 Intermediate bracket Zirkon 500/K+600/K Track marker Zirkon 500K +500KA Partly width switch off 4-Teilbreiten Tractor mounting set LH 5000 Tractor mounting set 4-Teilbreiten LH 5000 On board computer LH5000-GPS On board computer LH 5000 Cable form Solitair Electronic box LH 5000 Coupling 8x32x38 Coupling 1.3/4-6T Coupling 1.3/4-20Z Coupling 1.3/8-6Z HY-pipe assembly pole HY-pipe assembly Solitair EHA-A Relief pressure valve Solitair EHA-A Oil tank Solitair EHA-A Oil cooler Solitair EHA-A Pump Solitair EHA-A HY-assembly coulter lifting DZ63/30-245 Solitair B HY-assembly coulter frame D60-210 Solitair 9 KA HY-assembly track marker Solitair FW HY-assembly track marker Zirkon 9/500-K Drive wheel D540 2xD16 Drive wheel D540 IG W-90

1

2

3

4

5

6

7

8

9

10

11

12

Позиция на иллюстрации	Заводской номер детали		Название детали
1	321 9934		Warning board
2	321 9935		Warning board
3	373 2018		Junction box
4	373 2124		Plug
5	373 3130		Rear light, RH
6	373 3131		Rear light, LH
7	373 3526		Light glas
8	373 3527		Light glas
9	373 3801		Rear cover
10	373 4136		Cable, yellow
11	373 4137		Cable, green
12	373 4140		Cable

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
