HY-assembly coulter pressure DZ60-245 Solitair
HY-assembly coulter frame D60-210 Solitair 9 K
HY-assembly coulter frame D60-210 Solitair 9 KA
HY-assembly track marker Solitair FW
HY-assembly track marker Zirkon 400/450, 400K/450K
Drive wheel D540 IG W-90
Drive wheel D540 2xD16
Coupling 8x32x38
Coupling 1.3/4-6T
Coupling 1.3/4-20Z
Coupling 1.3/8-6Z
High-pressure hose Deichsel
High-pressure hose Solitair EHA-A
Relief pressure valve Solitair EHA-A
Oil tank Solitair EHA-A
Oil cooler Solitair EHA-A
Pump Solitair EHA-A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
18
19
Позиция на иллюстрации
Заводской номер детали
Название детали
1
301 2998
Bolt
2
301 4439
Bolt
3
303 0936
Selflocking nut
4
303 0967
Nut
5
305 2040
Shim
6
305 8861
Securing ring
7
313 7793
Pin
8
375 2121
Cap
9
375 2171
Throttle plate
10
375 2718
SVK-socket
11
375 4038
Nipple
12
375 4310
Union, swivel
13
375 4500
Adjustable angle union
14
375 4550
L-adjustable T-union
15
475 2598
High-pressure hose
16
475 2615
High-pressure hose
17
475 2656
High-pressure hose
18
575 2161
Nonreturn valve
19
575 2314
Plunger-ram
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
