1
2
3
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
301 5004
Screw
2
301 5858
Allen screw
3
303 0933
Selflocking nut
4
305 6132
Washer
5
325 1190
Hose clip
6
377 4120
Flexible hose
7
473 8043
Sensor holder
8
473 8044
Pulse pick-up
9
575 4801
Hydraulic motor
10
575 4810
Hydraulic motor
11
582 5680
Fan
12
482 5064
Tube turn
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
