Каталог запасных частей к технике: Lemken Primus 10 (Часть 2). 67710109 Compressed-air brake
1
2
8
9
10
11
12
13
13
14
14
14
15
15
16
17
17
17
18
18
18
19
19
20
20
20
20
21
21
21
21
22
22
24
24
25
25
26
26
27
28
29
30
30
31
31
32
33
38
39
41
42
45
46
46
47
47
48
48
48
50
50
52
52
53
54
55
56
56
57
57
58
58
58
59
61
62
63
64
65
66
67
68
70
85
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 37710054 | Hose coupling of air brake | |
| 2 | 37710053 | Hose coupling of air brake | |
| 8 | R00 0559 | Compressed-air container | |
| 9 | R00 0568 | Spiral hose | |
| 10 | R00 0569 | Spiral hose | |
| 11 | R00 0654 | Strap | |
| 12 | R00 0692 | Link | |
| 13 | R00 0712 | Connector | |
| 14 | R00 0713 | Connector | |
| 15 | R00 0714 | Screwed socket | |
| 16 | R00 0715 | Nipple | |
| 17 | R00 0716 | Screwed socket | |
| 18 | R00 0718 | Connector | |
| 19 | R00 0719 | Connector | |
| 20 | R00 0722 | Straight bulkhead screw | |
| 21 | R00 0723 | Nut | |
| 22 | R00 0726 | T-piece | |
| 24 | R00 0855 | Connector | |
| 25 | R00 0856 | Connector | |
| 26 | R00 0857 | Connector | |
| 27 | R00 0858 | Straight bulkhead screw | |
| 28 | R00 0859 | Nut | |
| 29 | R00 0861 | Nut | |
| 30 | 377 1180 | Thrust ring with O-ring | |
| 31 | 377 1181 | Thrust ring with O-ring | |
| 32 | R00 4243 | Compressed-air container | |
| 33 | R00 4245 | Strap | |
| 38 | R74 1550 | Holder | |
| 39 | 301 7510 | Hexagon bolt | |
| 41 | 301 7534 | Hexagon bolt | |
| 42 | 30110138 | Hexagon bolt | |
| 43 | 377 1490 | Plug | |
| 45 | 30210048 | Threaded rod | |
| 46 | 30310029 | Selflocking nut | |
| 47 | 30310043 | Selflocking nut | |
| 48 | 305 8695 | Washer | |
| 50 | 30510066 | Washer | |
| 52 | 377 1340 | Test coupling | |
| 53 | 377 1341 | Test coupling | |
| 54 | 377 1380 | Dewatering valve | |
| 55 | 377 1482 | Reducing fitting | |
| 56 | 37710046 | Synthetic tube | |
| 57 | 37710047 | Synthetic tube | |
| 58 | 37710048 | Synthetic tube | |
| 59 | 37710049 | Synthetic tube | |
| 61 | 577 2580 | Filter | |
| 62 | R00 0850 | Valve | |
| 63 | R00 0789 | Trailer brake valve | |
| 64 | R00 0556 | Shuttle valve | |
| 65 | 57710041 | Combi - brake cylinder | |
| 66 | R00 0711 | Regulator | |
| 67 | R00 0698 | Overflow valve | |
| 68 | R00 0709 | Valve | |
| 70 | R00 0666 | Forkpiece | |
| 71 | 37710097 | Elbow union | |
| 72 | 30510070 | Washer | |
| 85 | 301 6751 | Hexagon bolt | |
| 87 | 30310030 | Selflocking nut | |
| 89 | 305 8709 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
