Каталог запасных частей к технике: Lemken OptiDisc 25. 357 6001 Pressure roller cpl.

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано Achat 9/400 KA (2004) Achat 9/500 KA (2004) Achat 9/600 KA (2004) Azurit 9 (2018) Dolomit 9 (2010) EuroDiamant 10 (2010) EuroDiamant 10 X (2010) EuroDiamant 8 (2010) EuroGranat 5 (2006) EuroGranat 6 (2006) EuroGranat 7 (2006) EurOpal 5 (2010) EurOpal 5HX (2010) EurOpal 6 (2010) EurOpal 7 (2010) EurOpal 7, EurOpal 7HX (2018) EurOpal 7X (2010) EurOpal 7X, EurOpal 7 HydriX (2018) EurOpal 8 (2010) EurOpal 9 (2010) EuroTitan 10 (2010) EuroTitan 10X (2010) FixPack (2010) Gigant 1000 (2010) Gigant 1000 Smaragd (2010) Gigant 800 (2010) Gigant 800 S (2010) Gigant 800 S Rubin (2006) Gigant 800 Smaragd (2010) Heliodor 9/600KA (2018) Heliodor 9/700KA (2018) Juwel 8M (2018) Karat 9/600 KA (2016) Kristall 9/500KA (2016) Kristall 9/600KA (2016) OptiDisc 25 (2018) Primus 10 (Часть 1) (2017) Primus 10 (Часть 2) (2017) Quarz 7/250 (2010) Quarz 7/250 F (2010) Quarz 7/300 (2010) Quarz 7/300F (2010) Quarz 7/400 (2010) Quarz 7/400F (2010) Quarz 7/400K (2010) Quarz 7/400KA (2010) Quarz 7/500K (2010) Quarz 7/500KA (2010) Quarz 7/600K (2010) Rubin 10/600 KUA (2018) Rubin 10/700 KUA (2018) Rubin 12/400 KUA (A) (2018) Rubin 12/500 KUA (A) (2018) Rubin 12/600 KUA (A) (2018) Rubin 12/700 KUA (2018) Rubin 9/300 U (2004) Rubin 9/400 U (2004) Saphir 7/300 (2010) Saphir 7/400 (2010) Smaragd 7/260 (2010) Smaragd 7/300 (2010) Smaragd 9/300 (2010) Smaragd 9/400 (2010) Smaragd 9/400 (2016) Smaragd 9/400 K (2016) Smaragd 9/400K (2010) Smaragd 9/450K (2010) Smaragd 9/500 K (2016) Smaragd 9/500K (2004) Smaragd 9/600 K (2016) Smaragd 9/600K (2010) Smaragd 9/600KA (2010) Solitair 10/600K (2006) Solitair 12/1000K (2007) Solitair 12/1200K (2008) Solitair 12/1200KD (2018) Solitair 12/5800SW (2018) Solitair 12/800K (2006) Solitair 12/900K (2007) Solitair 8/300 (2004) Solitair 8/300 (2014) Solitair 8/400 (2004) Solitair 9/300 (2004) Solitair 9/400 (2004) Solitair 9/400K (2004) Solitair 9/400KA (2004) Solitair 9/450K (2004) Solitair 9/450KA (2004) Solitair 9/500K (2004) Solitair 9/500KA (2009) Solitair 9/600K (2004) Solitair 9/600KA (2004) System-Kompaktor Gigant 1000 (2010) System-Kompaktor Gigant 800 (2010) System-Kompaktor K450 (2010) System-Kompaktor K450A (2010) System-Kompaktor K500 (2010) System-Kompaktor K500A (2010) System-Kompaktor K600 (2010) System-Kompaktor K600A (2010) System-Kompaktor S300 (2010) System-Kompaktor S400 (2010) System-Korund 300 L (2010) System-Korund 450 L (2010) System-Korund 600 L (2010) System-Korund 750 K (750 L) (2010) System-Korund 900 K (2010) System-Korund 900 L (2010) Thorit 8/300 (2005) Thorit 8/300 Combi-Liner (2004) Thorit 8/400 (2010) Thorit 8/400 Combi-Liner (2004) Thorit 9/400 K (2004) Thorit 9/400 KA (2003) Thorit 9/450 K (2004) Thorit 9/500 K (2004) Thorit 9/500 KA (2003) Thorit 9/600 K (2004) Thorit 9/600 KA (2003) Topas 140-A (2010) Vari-Diamant 10 (2004) Vari-Diamant 10X (2004) Vari-Opal 100 (2014) Vari-Opal 100HX (2014) Vari-Opal 100X (2014) Vari-Opal 160 (2014) Vari-Opal X160 (2014) Vari-Titan 10 (2010) Vari-Turmalin 10 (2005) Vari-Turmalin 10X (2005) Variopack 110DP70 (2010) Variopack 110DP90 (2010) Variopack 110EP90 (2010) Variopack 110FEPK700 (2010) Variopack 80DP70 (2010) Variopack S 110DP70 (2010) VariOpal 5 (2010) VariOpal 7 (2010) VariOpal 7X (2010) VariOpal 8 (2010) VariOpal 8X (2010) VariOpal 9 (2010) VariOpal 9X (2010) Zirkon 10/300 (2010) Zirkon 10/400 (2010) Zirkon 10/400K (2010) Zirkon 10/450 (2010) Zirkon 10/450K (2010) Zirkon 10/450KA (2010) Zirkon 10/500K (2010) Zirkon 10/500KA (2010) Zirkon 10/600KA (2010) Zirkon 7/250 (2010) Zirkon 7/300 (2010) Zirkon 7/400 (2010) Zirkon 9/300 (2010) Zirkon 9/400 (2010) Zirkon 9/600K "B" (2010)

Схема > Не выбрано 30210077 CONTENTS 30210077 Turnbuckle 32110103 Spanner 59010132 Label set 58210234 Lateral section 58210235 Lateral section 58210236 Lateral section 58210237 Lateral section 58210238 Lateral section 58210239 Lateral section 58210240 Lateral section mounted 58210241 Lateral section 58210242 Lateral section 58210243 Lateral section 58210244 Lateral section 58210245 Lateral section 58210246 Lateral section 58210247 Lateral section 58210248 Lateral section 58210249 Lateral section 58210250 Holder coupling 68210220 Coulter frame 68210221 Coulter frame 68210222 Coulter frame 68210223 Coulter frame 68210224 Coulter frame 68210225 Coulter frame 68210226 Coulter frame 68210227 Coulter frame 68210228 Coulter frame 68210243 Folding frame 68210244 Folding frame 68210245 Folding frame 68210246 Folding frame 68210247 Folding frame 68210248 Folding frame 68210249 Folding frame 68210250 Folding frame 68210251 Folding frame 68210252 Folding frame 68210253 Folding frame 68210254 Folding frame 68210255 Carrier tube 68210256 Carrier tube 68210272 Holder 68210273 Holder 68210336 Coulter frame 68210338 Coulter frame 68210445 Hose guiding 313 7945 Top link pin with chain 661 1407 Lower link connection 66110029 Lower link connection 62910026 Stand 68210481 Depth indicator 670 5094 Transport protection 617 8147 Hydraulic locking device 575 2266 Hydraulic ram 575 2336 Hydraulic ram 575 5787 Piston rod 57510082 Hydraulic ram 57510616 Seat valve 57510885 Electrovalve 57510981 Hydraulic ram 57511012 Hydraulic ram 57511318 Piston rod 67510744 HY-assembly harrow 67510789 HY-assembly folding device 67510790 HY-assembly folding device 67510791 Hydraulic assembly 67510793 HY-assembly tramline 67510794 HY-assembly tramline 67510795 Hydraulic assembly 67510796 HY-assembly tramline 67510797 HY-assembly tramline 67510798 HY-assembly tramline 67510799 HY-assembly tramline 67510800 HY-assembly pre-emergence 67510801 Hydraulic assembly 67510826 Holder 67510829 Control valve 67510830 Control valve 67510831 Control valve 67510832 Control valve 67510835 HY supply pipe control valve 67510849 Hydraulic assembly 67510853 HY supply pipe control valve 67510854 Supply pipe 67510882 Control valve 67511014 HY-assembly harrow 67511294 Tramline mechanism 67511295 Tramline mechanism 68210435 Control 68210436 Control 57310471 Cable form 570 1764 Lighting unit 570 1765 Lighting unit 57010016 Lighting unit 57010017 Lighting unit 57010108 Lighting unit 57010109 Lighting unit 57010136 Lighting unit 57010137 Lighting unit 57010138 Lighting unit 57010159 Lighting unit 67010203 Lighting equipment 67010232 Lighting equipment 67310178 Seed pipe monitoring 67310179 Sensory mechanism 67310288 Seed pipe monitoring 68210319 Sensor seeding bar 357 6001 Pressure roller cpl. 58210124 Levelling harrow 58210125 Levelling harrow 58210126 Levelling harrow 58210127 Levelling harrow 682 6376 Scraper 68210110 Double disc coulter + roller 68210111 Double disc coulter + roller 68210172 Double disc coulter + spring 68210173 Double disc coulter 68210232 Compact-harrow 68210233 Compact-harrow 68210234 Compact-harrow 68210235 Compact-harrow 68210236 Compact-harrow 68210237 Compact-harrow 68210238 Compact-harrow 68210239 Compact-harrow 68210240 Harrow adjustment mec. 68210241 Single harrow 68210270 Single harrow with scraper 68210300 Double disc coulter 68210301 Double disc coulter 68210302 Double disc coulter 68210303 Double disc coulter 68210320 Single harrow 68210321 Single harrow with scraper 68210403 Harrow adjustment HY 68210433 Harrow adjustment mec. 555 4520 Bearing 58210119 Pre-emergency marker 682 2519 Pulse wheel 682 2520 Drive wheel 68210229 Pre-emergency marker 68210230 Pre-emergency marker 68210231 Pre-emergency marker 68210271 Bracket 58210056 Tramline cartridge 58210057 Tramline cartridge 58210058 Tramline cartridge 58210059 Tramline cartridge 58210074 Dees pipe with scraper 58210075 Dees pipe with HM-scraper 58210094 Tramline cartridge 58210095 Tramline cartridge 58210096 Tramline cartridge 58210097 Tramline cartridge 58210100 Tramline cartridge 58210101 Tramline cartridge 58210102 Tramline cartridge 58210104 Tramline cartridge 58210122 Tramline cartridge 58210134 Seed pipe 58210135 Seed pipe with HM-scraper 58210129 Flexible hose 58210132 Flexible hose 58210213 Fittings 68210274 Supply pipe set 68210275 Supply pipe set 68210276 Supply pipe set 68210277 Supply pipe set 68210278 Supply pipe set 68210279 Supply pipe set 68210280 Supply pipe set 68210281 Supply pipe set 68210456 Supply pipe 68210457 Supply pipe 68210463 Supply pipe 68210466 Supply pipe 68210258 Distributor 68210259 Distributor ring 68210260 Distributor 68210261 Distributor ring 68210262 Distributor 68210263 Distributor ring 68210264 Distributor 68210265 Tramline mechanism 68210267 Distributor 68210268 Distributor ring 699 6900 Seeding bar 699 6901 Seeding bar 699 6902 Seeding bar 699 6903 Seeding bar 699 6904 Seeding bar 699 6905 Seeding bar 699 6906 Seeding bar 699 6907 Seeding bar 699 6908 Seeding bar

1

2

3

4

5

Позиция на иллюстрации	Заводской номер детали		Название детали
1	319 8563		Bearing
2	357 6002		Wheel centre
3	357 6003		Tyre
4	317 7663		Bushing
5	319 8702		Bearing

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
