Каталог запасных частей к технике: Lemken EuroTitan 10X. Uni-wheel VE9 10.0/75-15,3
1
2
3
4
5
6
7
8
8
9
10
11
11
12
12
12
12
13
14
15
15
16
17
18
18
19
19
20
20
21
21
21
22
23
24
24
25
26
27
28
29
30
31
31
32
33
34
34
35
36
37
38
39
40
40
41
42
43
44
45
46
47
48
49
50
51
53
54
55
56
57
58
59
60
61
62
63
64
65
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 301 3497 | Bolt | |
| 2 | 301 3918 | Bolt | |
| 3 | 301 4523 | Bolt | |
| 4 | 301 4118 | Bolt | |
| 5 | 301 4573 | Bolt | |
| 6 | 301 4646 | Bolt | |
| 7 | 301 5370 | Bolt | |
| 8 | 303 0956 | Nut | |
| 9 | 303 0972 | Nut | |
| 10 | 303 0335 | Grooved nut | |
| 11 | 303 0976 | Nut | |
| 12 | 303 0977 | Nut | |
| 13 | 303 0978 | Nut | |
| 14 | 303 0980 | Nut | |
| 15 | 303 0990 | Nut | |
| 16 | 305 6148 | Shim | |
| 17 | 305 8545 | Securing ring | |
| 18 | 305 8551 | Securing clip | |
| 19 | 305 9888 | Spring ring | |
| 20 | 305 9889 | Spring ring | |
| 21 | 305 9887 | Spring ring | |
| 22 | 311 9565 | Securing pin | |
| 23 | 309 6053 | Expansion bush | |
| 24 | 311 9302 | Securing pin | |
| 25 | 313 1615 | Pin with grip | |
| 26 | 313 4018 | Pin | |
| 27 | 313 1213 | Pin with grip | |
| 28 | 313 8054 | Pin with stop | |
| 29 | 315 8006 | Rivet | |
| 30 | 313 4023 | Pin | |
| 31 | 317 2005 | Expansion bush | |
| 32 | 317 3336 | Expansion bush | |
| 33 | 317 3338 | Expansion bush | |
| 34 | 317 6672 | Tube | |
| 35 | 317 6673 | Tube | |
| 36 | 317 6907 | Ring | |
| 37 | 317 7504 | Bush | |
| 38 | 317 7510 | Tube | |
| 39 | 317 9310 | Flange bushing | |
| 40 | 323 6348 | Grease nipple | |
| 41 | 329 8496 | Spring | |
| 42 | 331 6130 | Chain | |
| 43 | 331 6246 | Chain | |
| 44 | 331 8380 | Shackle | |
| 45 | 331 9012 | Hook | |
| 46 | 449 1701 | Rod | |
| 47 | 448 2603 | Locking device | |
| 48 | 448 2605 | Stop | |
| 49 | 549 5750 | Cross union | |
| 50 | 449 5751 | Swivel bearing | |
| 51 | 449 5752 | Part of bracket | |
| 52 | 449 5774 | Bearing plate | |
| 53 | 449 5775 | Bearing plate | |
| 54 | 449 5755 | Stop | |
| 55 | 449 5756 | Holder | |
| 56 | 449 5757 | Adjuster plate | |
| 57 | 449 5754 | Wheel stalk with bearing | |
| 58 | 549 8894 | Bearing | |
| 59 | 550 8863 | Wheel 6/161/205 D18 | |
| 60 | 449 1642 | Scraper | |
| 61 | 301 3313 | Screw | |
| 62 | 303 0972 | Nut | |
| 63 | 305 9902 | Spring ring | |
| 64 | 317 9373 | Flange bushing | |
| 65 | 449 1713 | Rod |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
