Каталог запасных частей к технике: KUHN PLANTER II. SINGLE BAR
4
4
14
14
15
16
17
17
17
17
17
17
17
17
17
17
18
18
18
18
18
18
18
18
18
18
19
20
20
20
20
20
20
21
22
23
24
25
25
26
27
28
28
29
30
30
31
32
34
35
36
37
38
39
40
41
42
43
46
48
49
56
58
58
59
60
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
61
62
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4 | FNB1388A | STICKER | |
| 4 | FNB1386A | STICKER | |
| 14 | N00271A0 | SET OF STICKERS | |
| 14 | N00270A0 | SET OF STICKERS | |
| 15 | FNB0843 | COVER GASCKET | |
| 16 | FNB0842 | COVER GASCKET | |
| 17 | VNB2522A | HOODING | |
| 17 | N01057A0 | CENTRAL LEFT AIR BOX PL. FOLDA | |
| 17 | VNB0476A | HOODING | |
| 17 | VNB3010 | HOODING | |
| 17 | VNB0470A | HOODING | |
| 17 | VNB2520A | HOODING | |
| 17 | VNB2026C | HOODING | |
| 17 | VNB0474A | HOODING | |
| 17 | VNB2522A | HOODING | |
| 17 | VNB0472A | HOODING | |
| 18 | VNB2025C | HOODING | |
| 18 | N01058A0 | CENTRAL RIGHT AIR BOX PL FOLDA | |
| 18 | VNB0477A | HOODING | |
| 18 | VNB3011 | HOODING | |
| 18 | VNB0471A | HOODING | |
| 18 | VNB2521A | HOODING | |
| 18 | VNB2519A | HOODING | |
| 18 | VNB0475A | HOODING | |
| 18 | VNB2521A | HOODING | |
| 18 | VNB0473A | HOODING | |
| 19 | VNB0684 | CORNER | |
| 20 | FNB0109 | BEAM | |
| 20 | FNB0110 | BEAM | |
| 20 | FNB0111 | TUBE | |
| 20 | FNB0112 | TUBE | |
| 20 | FNB0113 | TUBE | |
| 20 | FNB0114 | TUBE | |
| 21 | FNB2081 | PLUG | |
| 22 | FNB1261A | STICKER | |
| 23 | 80200631 | SELF-LOCKING NUT INOX | |
| 24 | A621813 | DUST | |
| 25 | FNB1116 | ARTICULATED DEFLECTORS | |
| 26 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 27 | 80060833 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 28 | 80201070 | NUT FE/ZNXC3 | |
| 29 | 80271001 | SERRATED LOCK WASHER FLZNNC | |
| 30 | 83040188 | END PLUG | |
| 31 | FNB0846 | FLAT | |
| 32 | 80251120 | PLAIN WASHER ZBC | |
| 34 | 80201470 | NUT FE/ZNXC3 | |
| 35 | FLA0954C | WASHER | |
| 36 | 80061036 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 37 | FNB0851 | CLIP | |
| 38 | VNB0622 | BRACKET | |
| 39 | FNB0429A | CLAMP | |
| 40 | 83090122 | DRAG COLLAR | |
| 41 | 83673008 | PIPE PVC Ш46,5, OREGON | |
| 42 | FNB1002 | DUST | |
| 43 | FNB2053A | OUTLET LOWER PART | |
| 46 | A621367 | DUCT | |
| 48 | FNB0844 | CLIP | |
| 49 | 83090082 | COLLAR | |
| 56 | FNB1269 | BRACKET | |
| 58 | 80061016 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 58 | 80141010 | SET SCREW WITH CONE FE/ZNXC3 | |
| 59 | N01716B0 | BUSH | |
| 60 | N02421A0 | TUBE | |
| 61 | N01745A0 | HEXAGON BAR | |
| 61 | N01746A0 | HEXAGON BAR | |
| 61 | N01747A0 | HEXAGON | |
| 61 | N01748A0 | HEXAGON BAR | |
| 61 | N01749A0 | HEXAGON BAR | |
| 61 | N02352A0 | HEXAGON | |
| 61 | N02353A0 | TUBE | |
| 62 | N01843A0 | PLUG |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
