Каталог запасных частей к технике: KUHN PLANTER II. MICROGRANULATOR HOPPER

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
3
4
5
5
5
6
6
6
7
8
9
10
11
12
13
14
15
16
16
17
19
20
21
22
22
22
22
22
22
23
23
23
23
23
23
24
25
26
27
28
29
30
31
32
32
32
33
34
34
34
34
34
34
35
35
35
38
38
40
40
40
40
40
40
48
48
48
48
48
48
49
49
49
50
50
50
51
52
54
55
56
57
58
59
60
63
64
64
65
66
67
68
69
70
71
72
73
74
74
75
76
77
Позиция на иллюстрации Заводской номер детали Название детали
1 80500229 SPLIT PIN FE/ZNXC3
3 FNB1156 SPANNER
4 80200866 UNDERSERRAT.S.LOCK.NUT INOX
5 80250717 PLAIN WASHER ZBC
6 80200665 UNDERSERRAT.S.LOC.NUT FE/ZNXC3
7 FNB1155A SPECIAL NUT
8 FNB1214 SPRING
9 FSE0418A PIN
10 80100830 SLOT.CHEESE GAED SCREW INOX A2
11 FNB0491 YOKE
12 FNB0488 FLAT
13 80271001 SERRATED LOCK WASHER FLZNNC
14 80201070 NUT FE/ZNXC3
15 FNB1058A SPRING
16 80060616 HEXAGON HEAD SCREW FE/ZNXC3
17 80250714 PLAIN WASHER ZBC
19 FNB0973 SPACER
20 80200665 UNDERSERRAT.S.LOC.NUT FE/ZNXC3
21 80060630 HEX BOLT FE/ZNXC3
22 VNB0467A EMPTYING TRAP
22 VNB0468A EMPTYING TRAP
22 VNB0469A EMPTYING TRAP
23 VNB0603 PLATE
23 VNB0646 PLATE
23 VNB0645 PLATE
24 FLA1564 PLATE
25 VLA0840 GRADUATION
26 80200627 WING NUT INOX A2
27 80250714 PLAIN WASHER ZBC
28 FLA1565A NEEDLE
29 80581800 RETAINING RING
30 80251932 PLAIN WASHER FE/ZNXC3
31 VLA0823A BRACKET
32 VNB0492A GEAR HOUSING
32 VNB0493A GEAR HOUSING
32 VNB0491A GEAR HOUSING
33 80060612 HEXAGON HEAD SCREW FE/ZNXC3
34 FNB0375 SEED GATE
34 FNB0376 SEED GATE
34 FNB0377 SEED GATE
34 FNB0378 SEED GATE
34 FNB0379 SEED GATE
34 FNB0380 SEED GATE
35 FNB1221A SHIELD
35 FNB1223A SHIELD
35 FNB1222A SHIELD
38 BLA0157 CAM ROLLER
40 VNB0489 HAND SCREEN
40 VNB0490 HAND SCREEN
40 VNB0488 HAND SCREEN
48 VNB0515A HOPPER
48 VNB3019 HOPPER
48 VNB3023 HOPPER
48 VNB3028 HOPPER
48 VNB3030 HOPPER
48 VNB3032 HOPPER
49 VNB0206 SIEVE
49 VNB3029 SIEVE
49 VNB0207 SIEVE
50 VNB0660 COVER
50 VNB3020 COVER
50 VNB3031 COVER
51 VLA0840 GRADUATION
52 FJX0201B FLAT
54 FHX2097C SPRING
55 N00176A0 SKID
56 N00806A0 REINFORCING SHIELD
57 FNB0236 SPRING
58 N00736A0 BRACKET
59 N00747B0 TENSIONER
60 80450666 ROLL PIN FLZNNC
63 80060840 HEX BOLT FE/ZNXC3
64 80200865 UNDERSERRAT.S.LOC.NUT FE/ZNXC3
65 80060816 HEXAGON HEAD SCREW FE/ZNXC3
66 80250931 PLAIN WASHER ZBC
67 B0000649 WASHER
68 80200870 NUT FE/ZNXC3
69 80270602 SERRATED LOCK WASHER FE/ZNXC3
70 80200600 NUT FE/ZNXC3
71 FLA1637A SPRING
72 80200631 SELF-LOCKING NUT INOX
73 80061046 HEXAGON HEAD SCREW ZBC
74 80201003 HEXAGON THIN NUT INOX A2
75 FNB0496 SPACER
76 VNB0205 TENSIONER
77 80101021 SLOT.CHEESE GAED SCREW INOX A2
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
