Каталог запасных частей к технике: KUHN PLANTER II. JUNIOR FAN
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
19
20
21
22
23
24
25
26
27
28
28
29
30
31
31
32
33
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
48
51
52
53
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | MLA0103 | 1/2 CRANKCASE | |
| 2 | 80250714 | PLAIN WASHER ZBC | |
| 3 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 4 | 80200600 | NUT FE/ZNXC3 | |
| 5 | 80200806 | NUT FE/ZNXC3 | |
| 6 | VLA0782 | SCREW | |
| 7 | FLA1715 | WASHER | |
| 8 | FLA1545 | WASHER | |
| 9 | 80200826 | WING NUT FE/ZNXC3 | |
| 10 | 80270602 | SERRATED LOCK WASHER FE/ZNXC3 | |
| 11 | FLA1462C | DIAPHRAGM | |
| 12 | MLA0102A | 1/2 CRANKCASE | |
| 13 | FLA1627A | SCREW | |
| 14 | FLA1626 | WASHER | |
| 15 | VLA0731 | TURBINE | |
| 16 | 80060612 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 17 | 81002050 | BALL BEARING | |
| 18 | 80060671 | HEXAGON HEAD SCREW INOX | |
| 19 | 80594700 | RETAINING RING | |
| 20 | FLA1608 | SPACER | |
| 21 | VLA1790 | SPECIAL NUT | |
| 22 | 80081005 | HEX.SOCKET HEAD CAP SCREW | |
| 23 | 80271084 | SPRING LOCK WASHER | |
| 24 | FLA0517B | 1/2 CRANKCASE | |
| 25 | VLA0206A | TURBINE | |
| 26 | 80271202 | SERRATED LOCK WASHER ZBC | |
| 27 | 80201270 | NUT FE/ZNXC3 | |
| 28 | 80200665 | UNDERSERRAT.S.LOC.NUT FE/ZNXC3 | |
| 29 | VLA2117 | 1/2 CRANKCASE | |
| 30 | FLA0528A | SPACER | |
| 31 | 80597200 | RETAINING RING | |
| 32 | 82153772 | FLEXIBLE AXIAL SEAL WASHER | |
| 33 | 81003074 | BALL BEARING | |
| 34 | VLA0803F | HUB | |
| 35 | MAD0006A | TERMINAL SOCKET | |
| 36 | A620234 | DUST | |
| 37 | VAD0159 | PIN | |
| 38 | VLA0805 | 1/2 ELASTIK KUPPLUNG | |
| 39 | FLA1231A | SPACER | |
| 40 | FJX0159 | SPACER | |
| 41 | FLA1227B | DEFLECTOR | |
| 42 | 80060695 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 43 | 80061061 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 44 | 80251021 | PLAIN WASHER M10 | |
| 45 | 80201070 | NUT FE/ZNXC3 | |
| 46 | FNB1059 | TENSIONER | |
| 47 | 80201014 | SQUARE WELD NUT | |
| 48 | K9500010 | LOGO 103 | |
| 48 | 09915000 | DECAL | |
| 51 | FLA0529C | PIN | |
| 52 | FLA1715 | WASHER | |
| 53 | 80250820 | PLAIN WASHER ZBC | |
| 54 | 80060685 | HEXAGON HEAD SCREW ZBC |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
