Каталог запасных частей к технике: KUHN PLANTER II. DECLUT CHING OF UNITS
1
2
3
4
5
6
7
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 2 | 80200600 | NUT FE/ZNXC3 | |
| 3 | N02895A0 | GEAR HOUSING | |
| 4 | N1001560 | CAP | |
| 5 | 80060631 | HEXAGON HEAD SCREW ZBC | |
| 6 | FJX0098D | SPACER | |
| 7 | VLT0072 | SOLENOID | |
| 7 | 83233206 | LUG RED 6,35 | |
| 7 | A621576 | SOLENOID | |
| 8 | 80500318 | SPLIT PIN FE/ZNXC3 | |
| 9 | N02793A0 | SUPPORT BASCULEUR | |
| 10 | N02798A0 | SPRING | |
| 11 | N02799A0 | GEAR WHEEL | |
| 12 | 80583000 | RETAINING RING | |
| 13 | 80253044 | SHIM WASHER | |
| 14 | 82062908 | O-RING | |
| 15 | 83010230 | SELF LUBRICATING BEARING | |
| 16 | 80061036 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 17 | 80201040 | SELF-LOCKING NUT FE/ZNXC3 | |
| 18 | N02802A0 | TUBE | |
| 19 | N02803A0 | HUB | |
| 20 | N02795A0 | WEIGHING | |
| 21 | 80060631 | HEXAGON HEAD SCREW ZBC | |
| 22 | 80200600 | NUT FE/ZNXC3 | |
| 23 | FJX0697 | SPRING | |
| 24 | 80250717 | PLAIN WASHER ZBC | |
| 25 | 80200600 | NUT FE/ZNXC3 | |
| 26 | N02794A0 | SUPPORT D'ELECTRO AIMANT |
