Каталог запасных частей к технике: KUHN PLANTER II. AXIAL ROLLER
1
2
2
3
4
4
5
6
6
7
8
8
9
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | N1000150 | PIN | |
| 2 | N02334A0 | SCRAPER | |
| 3 | N02335A0 | SCRAPER | |
| 4 | 80200665 | UNDERSERRAT.S.LOC.NUT FE/ZNXC3 | |
| 5 | 80200631 | SELF-LOCKING NUT INOX | |
| 6 | 80200840 | SELF-LOCKING NUT FE/ZNXC3 | |
| 7 | 80200655 | CLAMP NUT | |
| 8 | 80201070 | NUT FE/ZNXC3 | |
| 9 | FNB1384 | SPACER | |
| 10 | N1000130 | SPACER | |
| 11 | FPX0752 | ROD LONG | |
| 12 | 80500322 | SPLIT PIN FE/ZNXC3 | |
| 13 | 82200800 | GREASE NIPPLE FE/ZNXC3 | |
| 14 | 83070063 | PVC CORD | |
| 15 | FLA1524A | SPRING | |
| 16 | 80250714 | PLAIN WASHER ZBC | |
| 17 | 80250934 | PLAIN WASHER ZBC | |
| 18 | VLR0280 | STAINLESS STEEL WHEEL 28 | |
| 19 | FLA1736A | BRACKET | |
| 20 | FNB1385 | BRACKET | |
| 21 | N1000960 | SUPPORT | |
| 22 | VNB0687B | SUPPORT | |
| 23 | FNB1183C | ROD | |
| 24 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 25 | 80060692 | HEXAGON HEAD SCREW ZBC | |
| 26 | 80060696 | HEXAGON HEAD SCREW ZBC | |
| 27 | 80060826 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 28 | 80060864 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 29 | 80061036 | HEXAGON HEAD SCREW FE/ZNXC3 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
