Каталог запасных частей к технике: KUHN PLANTER 3M. SIDE MARKERS 6M00 D5412-E0785
1
2
2
3
4
5
6
6
7
8
8
9
10
10
11
11
12
13
14
14
15
16
16
16
17
18
19
20
21
22
23
23
24
24
25
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 80060620 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 2 | 80061073 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 3 | 80061249 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 4 | 80061601 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 5 | 80200640 | SELF-LOCKING NUT FE/ZNXC3 | |
| 6 | 80201040 | SELF-LOCKING NUT FE/ZNXC3 | |
| 7 | 80201231 | SELF-LOCKING NUT INOX | |
| 8 | 80201240 | SELF-LOCKING NUT FE/ZNXC3 | |
| 9 | 80201440 | SELF-LOCKING NUT FE/ZNXC3 | |
| 10 | 80251227 | PLAIN WASHER FE/ZNXC3 | |
| 11 | 80251535 | PLAIN WASHER FE/ZNXC3 | |
| 12 | 80500428 | SPLIT PIN FE/ZNXC3 | |
| 13 | 80560801 | TUBE PIN FE/ZNXC3 | |
| 14 | 81002050 | BALL BEARING | |
| 15 | 82200800 | GREASE NIPPLE FE/ZNXC3 | |
| 16 | 83012528 | WRAPPED BUSH | |
| 17 | 1626792 | KIT HYDRAULIK MARKERS 6M | |
| 18 | B0000751 | END PLUG | |
| 19 | FJA0284 | PLATE | |
| 20 | FJA0303 | STICKER | |
| 21 | FLA0954C | WASHER | |
| 22 | FNB0429A | CLAMP | |
| 23 | N1001290 | CRADLE | |
| 24 | N00039B0 | FLAT | |
| 25 | N00047A0 | PIN | |
| 26 | N00053C0 | SHEATH, RIGID | |
| 27 | N00056B0 | DISC | |
| 28 | N00105E0 | ARM | |
| 29 | N00106E0 | ARM | |
| 30 | N00346A0 | CUP | |
| 31 | N00644B0 | 1/2 BUSH | |
| 32 | N00650A0 | CUP | |
| 33 | N00684A0 | PIN | |
| 34 | N01143A0 | CUP | |
| 35 | N02342B0 | PIN | |
| 36 | N02343A0 | DISC | |
| 37 | N02347A0 | TUBE | |
| 38 | N03375A0 | U-BOLT | |
| 39 | VNB1020 | CUP | |
| 40 | VNB1021 | CUP | |
| 41 | VNB0124E | CLAMP, MOUNT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
