Каталог запасных частей к технике: KUHN PLANTER 3M. MICROGRANULATOR H 9X D5412-J0000
1
2
3
3
3
3
3
3
4
4
5
6
7
7
8
9
10
10
10
10
10
11
11
11
11
11
11
11
12
13
14
15
16
16
16
16
17
18
18
18
18
18
18
19
19
19
20
20
20
21
21
22
22
23
23
23
23
23
23
23
23
23
23
24
25
25
26
27
27
28
28
28
28
29
29
29
30
30
31
31
32
33
33
33
34
34
35
35
36
36
36
36
37
37
38
39
40
41
42
43
43
44
45
46
47
48
48
49
50
51
52
53
54
55
56
57
58
59
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 80030821 | CUP SQUARE BOLT FE/ZNXC3 | |
| 2 | 80060612 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 3 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 4 | 80060820 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 5 | 80060839 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 6 | 80061098 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 7 | 80141010 | SET SCREW WITH CONE FE/ZNXC3 | |
| 8 | 80190616 | SELF-CUTTING SCREW FE/ZNXC3 | |
| 9 | 80200655 | CLAMP NUT | |
| 10 | 80200665 | UNDERSERRAT.S.LOC.NUT FE/ZNXC3 | |
| 11 | 80200840 | SELF-LOCKING NUT FE/ZNXC3 | |
| 12 | 80201040 | SELF-LOCKING NUT FE/ZNXC3 | |
| 13 | 80250618 | PLAIN WASHER INOX A2 | |
| 14 | 80250823 | PLAIN WASHER FE/ZNXC3 | |
| 15 | 80251128 | PLAIN WASHER FE/ZNXC3 | |
| 16 | 80251932 | PLAIN WASHER FE/ZNXC3 | |
| 17 | 80270602 | SERRATED LOCK WASHER FE/ZNXC3 | |
| 18 | 80450530 | ROLL PIN FLZNNC | |
| 19 | 80560748 | LINCH PIN | |
| 20 | 80581800 | RETAINING RING | |
| 21 | 81502508 | FLANGE UNIT | |
| 22 | A620243 | HANDLE | |
| 23 | BLA0117B | PINION GEAR | |
| 24 | FLA1469 | PINION GEAR | |
| 25 | FLA1550 | WASHER | |
| 26 | FLA1468A | PINION GEAR | |
| 27 | FLA1563B | BEARING RING | |
| 28 | FLA1569B | BUSH | |
| 29 | FLA1571A | PLATE | |
| 30 | FLA1595A | WASHER | |
| 31 | FNB0361 | WASHER | |
| 32 | FNB0380 | SEED GATE | |
| 33 | K3603270 | SPACER | |
| 34 | K3603290 | SPACER | |
| 35 | K3607160 | WASHER, BELLEVILLE | |
| 36 | K3608320 | BUSHING | |
| 37 | K3626080 | STOP | |
| 38 | K3627370 | SHEET | |
| 39 | MLA0096A | GEAR, PINION | |
| 40 | MLA0097A | GEAR, PINION | |
| 41 | MLA0098A | GEAR, PINION | |
| 42 | MLA0156A | PINION GEAR | |
| 43 | N1509000 | GUIDE, SLIDE | |
| 44 | N00059A0 | GEAR, PINION | |
| 45 | N00088B0 | CHAIN | |
| 46 | N00089A0 | EMPTYING TRAP | |
| 47 | N00091C0 | HOUSING | |
| 48 | N00176A0 | SKID | |
| 49 | N00186B0 | PIN | |
| 50 | N00191A0 | LEVER | |
| 51 | N00192B0 | STICKER | |
| 52 | N00195C0 | CRANKCASE | |
| 53 | N00197A0 | PINION GEAR | |
| 54 | N00199A0 | BUSHING | |
| 55 | N00563B0 | PIN | |
| 56 | N03938A0 | TENSIONER | |
| 57 | VNB0603 | PLATE | |
| 58 | VNB0645 | PLATE | |
| 59 | VNB0646 | PLATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
