Каталог запасных частей к технике: KUHN PLANTER 3M. CONTROL 6M00 (ROW MARKER)
1
2
2
3
4
5
5
6
6
6
6
7
7
8
8
9
10
10
10
11
12
13
14
15
15
16
16
17
17
18
18
19
20
20
21
22
23
24
25
26
26
27
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1676573 | HYD CONTROL+SEQUENCE VALVE | |
| 2 | 80061249 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 3 | 80080831 | HEX.SOCK.HEAD CAP SCR.FE/ZNXC3 | |
| 4 | 80200840 | SELF-LOCKING NUT FE/ZNXC3 | |
| 5 | 80201230 | SELF-LOCKING NUT FE/ZNXC3 | |
| 6 | 80251535 | PLAIN WASHER FE/ZNXC3 | |
| 7 | 80500428 | SPLIT PIN FE/ZNXC3 | |
| 8 | 82300026 | CAP MALE CONNECTOR | |
| 9 | 82300089 | SEQUENCE VALVE | |
| 10 | 82300808 | MALE STUD CONNECTOR | |
| 11 | 83090192 | CABLE TIE PLASTIC | |
| 12 | 80251430 | PLAIN WASHER FE/ZNXC3 | |
| 13 | 82300810 | CONNECTOR | |
| 14 | 83090093 | HOSE BINDER | |
| 15 | А4074029 | CONNECTOR MALE | |
| 16 | А4075018 | VALVE, BALL | |
| 17 | А4080524 | ADAPTER ZBC | |
| 18 | А4082711 | AJUSTABLE MALE STUD ELBOW | |
| 19 | А4083203 | ADJUSTABLE EQUAL TEE FE/ZNXC3 | |
| 20 | А4080448 | MALE STUD CONNECTOR | |
| 21 | А4920117 | HOSE, HYDRAULIC | |
| 22 | А4920117 | HOSE, HYDRAULIC | |
| 23 | А4920117 | HOSE, HYDRAULIC | |
| 24 | А4920117 | HOSE, HYDRAULIC | |
| 25 | К3600260 | SET OIL SEALS FOR VNB0780B | |
| 26 | К3601320 | CYLINDER, HYDRAULIC | |
| 27 | К3611520 | PIN | |
| 28 | N02086A0 | HYDRAULIC HOSE | |
| 29 | N02086A0 | HYDRAULIC HOSE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
