Каталог запасных частей к технике: KUHN MULTI-LEADER T. SUPPORT ON-LAND L3850 >L9999
1
2
3
3
4
5
6
6
7
7
8
8
9
10
11
12
12
12
13
14
14
15
15
16
17
17
17
17
18
19
19
19
19
20
20
21
21
22
22
22
22
23
24
25
26
27
28
28
28
28
28
28
29
30
31
31
31
32
32
33
33
33
33
33
33
34
34
34
35
35
35
36
36
36
36
37
37
37
37
37
38
39
40
41
42
43
43
44
45
46
47
48
49
50
51
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 582742 | GUSSET, CORNER | |
| 2 | 780340 | GUSSET, CORNER | |
| 3 | 951521 | TENSION BUSH | |
| 4 | 80060616 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 5 | 80060820 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 6 | 80060826 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 7 | 80060835 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 8 | 80060840 | HEX BOLT FE/ZNXC3 | |
| 9 | 80060850 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 10 | 80060864 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 11 | 80061036 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 12 | 80061245 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 13 | 80061249 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 14 | 80062054 | HEXAGON HEAD SCREW FE/ZNXC3 | |
| 15 | 80080831 | HEX.SOCK.HEAD CAP SCR.FE/ZNXC3 | |
| 16 | 80200830 | SELF-LOCKING NUT FE/ZNXC3 | |
| 17 | 80200840 | SELF-LOCKING NUT FE/ZNXC3 | |
| 18 | 80201030 | SELF-LOCKING NUT FE/ZNXC3 | |
| 19 | 80201230 | SELF-LOCKING NUT FE/ZNXC3 | |
| 20 | 80202070 | NUT FE/ZNXC3 | |
| 21 | 80205566 | SELF-LOCKING NUT FE/ZNXC3 | |
| 22 | 80250823 | PLAIN WASHER FE/ZNXC3 | |
| 23 | 80251021 | PLAIN WASHER M10 | |
| 24 | 80251227 | PLAIN WASHER FE/ZNXC3 | |
| 25 | 80251624 | PLAIN WASHER FE/ZNXC3 | |
| 26 | 80270684 | WASHER, SPRING LOCK | |
| 27 | 80270803 | SPRING WASHER M8 DIN127 | |
| 28 | 82201016 | SELF TAPPING GREASE NIPPLE | |
| 29 | 83014040 | WRAPPED BUSH | |
| 30 | A4071228 | VALVE, FLAP | |
| 31 | A4080300 | STRAIGHT COUPLING ZBC | |
| 32 | A4080302 | BULKHEAD UNION | |
| 33 | A4080401 | MALE STUD CONNECTOR | |
| 34 | A4082700 | AJUSTABLE MALE STUD ELBOW | |
| 35 | A4921017 | HYDRAULIC HOSE | |
| 36 | A7260016 | UPPER PLATE SIZE 2 | |
| 37 | A7260042 | CLAMP D15+D15 | |
| 38 | A7260060 | INTERMEDIATE SCREW M8X29 | |
| 39 | A4921017 | HYDRAULIC HOSE | |
| 40 | A4921017 | HYDRAULIC HOSE | |
| 41 | A4921076 | HYDRAULIC HOSE | |
| 42 | A4921076 | HYDRAULIC HOSE | |
| 43 | H0100350 | STOP PLATE | |
| 44 | H0103020 | CYLINDER, HYDRAULIC | |
| 45 | H0103030 | KIT, SEAL | |
| 46 | H0104010 | PIN | |
| 47 | H0105120 | PIN | |
| 48 | H0205090 | PIN | |
| 49 | H0205100 | PIN | |
| 50 | H0207361 | HOUSING | |
| 51 | H0208221 | LINK, CONNECTING | |
| 52 | H0209210 | BRACKET | |
| 53 | H0209700 | SHIM | |
| 54 | H0605920 | SHIM | |
| 55 | H0606190 | BRACKET |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
