Каталог запасных частей к технике: KRONE BIG-X-V8/BIG-X-V12. Terminals and connectors

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
2
2
3
4
4
5
6
7
8
9
9
9
9
9
9
9
10
10
10
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
Позиция на иллюстрации Заводской номер детали Название детали
003023570 003023570 Plug, LED/Varistor- transparent
003019870 003019870 Valve plug with LED
003018020 003018020 Solenoid valve plug-black
2 003021820 Screw with straight-line curls
3 003023590 Valve plug-black
4 003011860 Gasket
5 003031721 Adapter wire-4-pole
6 003032271 Adapter wire-4-pole
7 003031140 Jet-plug-2-pole
8 003031151 Jet-plug-3-pole
9 003037540 Cable terminal-red
9 003018270 Cable terminal-red
9 003022770 Cable terminal-blue
9 003031300 Cable terminal-blue
9 003016670 Cable terminal-yellow
9 009440820 Cable terminal-yellow
9 003037560 Cable terminal-yellow
10 009246940 Flat sleeve-red
10 009246960 Flat sleeve-yellow
10 009246950 Flat sleeve
10 009247010 Flat sleeve-red
10 009246150 Flat sleeve-red
11 003026880 Flat sleeve-red
11 003026890 Flat sleeve-blue
12 003024270 Plug-19-pole
13 003024310 Plug-31-pole
14 003024260 Socket-19-pole
15 003024301 Socket-31-pole
16 003034260 AMP-circular plug-7-pole
17 003031160 AMP-circular plug-4-pole
18 003030840 Plug-10-pole
19 003030850 Plug-6-pole
20 003030730 Bushing housing-10-pole
21 003030820 Bushing housing-6-pole
22 003030830 Bushing housing-16-pole
23 003023620 Plug-42-pole
24 003025410 CAN-plug EMR-16-pole
25 003030920 Main plug-lateral
26 003030930 Main plug
27 003030990 Attaching housing-cpl.
28 003023510 Plug-2-pole
29 003023520 Plug-3-pole
30 003023530 Plug-4-pole
31 003023560 Coupling socket-2-pole
32 003023550 Coupling socket-3-pole
33 003023540 Coupling socket-4-pole
34 003033150 Socket-2-pole
35 003033160 Plug-2-pole
36 003029670 Blind bushing plug-3-pole
37 003033790 Blind-pin casing-3-pole
38 003029830 Blind bushing casing-2-pole
39 003020481 Attaching housing-7-pole
40 003020510 Protective cap
41 003020311 Plug-7-pole
42 003034120 Valve plug-black , low mounting form
43 003030651 Sосkеt-14-pоlе
44 003021960 Flat fuse
45 003015540 Reversing relay
46 009245710 Socket-7-pole
47 003033470 Blind-plug
48 003031200 Plug-2-pole
49 003031310 Plug-3-pole
50 003023650 Plug-2-pole
51 003031050 Plug-2-pole
52 003039690 Blind-plug-2-pole
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
