Каталог запасных частей к технике: KRONE BIG-X-V8/BIG-X-V12. Terminals and connectors

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
2
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
42
44
44
44
44
44
44
44
44
44
45
46
47
48
Позиция на иллюстрации Заводской номер детали Название детали
003023570 003023570 Plug, LED/Varistor- transparent
003019870 003019870 Valve plug with LED
2 003021820 Screw with straight-line curls
3 003023590 Valve plug-black
4 003011860 Gasket
5 003031720 Adapter wire-4-pole
6 003032270 Adapter wire-4-pole
7 003031140 Jet-plug-2-pole
8 003031150 Jet-plug-3-pole
9 003037540 Cable terminal-red
9 003018270 Cable terminal-red
9 003022770 Cable terminal-blue
9 003031300 Cable terminal-blue
9 003016670 Cable terminal-yellow
9 009440820 Cable terminal-yellow
9 003037560 Cable terminal-yellow
10 009246950 Flat sleeve
10 009246960 Flat sleeve-yellow
10 009246940 Flat sleeve-red
10 009247010 Flat sleeve-red
10 009246150 Flat sleeve-red
11 003026880 Flat sleeve-red
11 003026890 Flat sleeve-blue
12 003024270 Plug-19-pole
13 003024310 Plug-31-pole
14 003024260 Socket-19-pole
15 003024300 Socket-31-pole
16 003034260 AMP-circular plug-7-pole
17 003031160 AMP-circular plug-4-pole
18 003030840 Plug-10-pole
19 003030850 Plug-6-pole
20 003030730 Bushing housing-10-pole
21 003030820 Bushing housing-6-pole
22 003030830 Bushing housing-16-pole
23 003023620 Plug-42-pole
24 200821760 Connector 16-p socket cpl.-16-pole
25 003030920 Main plug-lateral
26 003030930 Main plug
27 003030990 Attaching housing-cpl.
28 003023510 Plug-2-pole
29 003023520 Plug-3-pole
30 003023530 Plug-4-pole
31 003023560 Coupling socket-2-pole
32 003023550 Coupling socket-3-pole
33 003023540 Coupling socket-4-pole
34 003033150 Socket-2-pole
35 003033160 Plug-2-pole
36 003029670 Blind bushing plug-3-pole
37 003033790 Blind-pin casing-3-pole
38 003029830 Blind bushing casing-2-pole
39 003020481 Attaching housing-7-pole
40 003020510 Protective cap
41 003020311 Plug-7-pole
42 003034120 Valve plug-black , low mounting form
44 003020790 Flat fuse
44 003031980 Flat fuse
44 003019770 Flat fuse
44 003020740 Flat fuse
44 003020760 Flat fuse
44 003021940 Flat fuse
44 003018560 Flat fuse
44 003032010 Flat fuse
44 003021960 Flat fuse
45 003015540 Reversing relay
46 009245710 Socket-7-pole
47 003033470 Blind-plug
48 003031200 Plug-2-pole
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
