Каталог запасных частей к технике: KRONE BiG X V8, BiG X V12. Front panel / Headlight
00 924 714 0
00 924 714 0
00 924 688 0
00 924 688 0
20 080 761 0
20 080 761 0
00 924 693 0
00 924 693 0
00 924 709 0
00 924 709 0
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
6
7
8
8
9
9
10
11
11
12
13
13
13
13
13
14
14
15
16
17
18
18
19
20
20
20
21
22
22
23
24
25
26
27
28
28
28
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 924 714 0 | 00 924 714 0 | Bulb | |
| 00 924 688 0 | 00 924 688 0 | Bulb | |
| 20 080 761 0 | 20 080 761 0 | Pane | |
| 00 924 693 0 | 00 924 693 0 | Singel filament buld | |
| 00 924 709 0 | 00 924 709 0 | Singel filament buld | |
| 1 | 00 908 212 0 | Hex nut | |
| 2 | 00 910 414 0 | Washer | |
| 3 | 00 217 545 0 | Fastening angle | |
| 4 | 00 910 603 0 | Washer | |
| 5 | 00 908 210 0 | Hex nut | |
| 6 | 00 900 636 0 | Hex head bolt | |
| 7 | 00 217 405 0 | Front guard -right | |
| 8 | 00 924 636 0 | Flashing light with side light | |
| 9 | 00 924 744 0 | Headlight -outside | |
| 10 | 00 223 021 3 | Front buffle | |
| 11 | 00 924 637 0 | Headlight -middle | |
| 12 | 00 222 979 0 | Support -left | |
| 13 | 00 908 758 0 | Locknut | |
| 14 | 00 900 634 0 | Hex head bolt | |
| 15 | 00 900 655 0 | Hex head bolt | |
| 16 | 00 225 389 0 | Support -middle | |
| 17 | 00 222 980 1 | Support -right | |
| 18 | 00 302 724 0 | Feeler -green | |
| 19 | 00 303 181 0 | Sticker hand operation -sharpening | |
| 20 | 00 302 723 0 | Feeler -yellow | |
| 21 | 00 217 406 0 | Front guard -left | |
| 22 | 00 910 609 0 | Washer | |
| 23 | 00 908 215 0 | Hex nut | |
| 24 | 00 303 175 0 | Wiring harness -hand operation | |
| 25 | 00 303 195 0 | Wiring harness -right | |
| 26 | 00 303 194 0 | Wiring harness left | |
| 27 | 00 303 193 0 | Wiring harness -middle | |
| 28 | 00 909 908 1 | Detent edged washer | |
| 29 | 00 940 375 0 | Repairing set for plastics - beige | |
| 30 | 00 303 562 0 | Feeler -incl. tag | |
| 31 | 00 303 419 0 | Tag -feeder/front attachement reverser | |
| 32 | 00 303 417 0 | Tag -lift lifting gear | |
| 33 | 00 303 418 0 | Tag -lower lifting gear |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
