Каталог запасных частей к технике: KRONE BIG-X-850-1. Steering columm
270067260
270078960
270102340
270169450
270174800
270174790
270174780
270174770
270174760
270174740
270174730
270174710
270174690
270067280
270067270
270174750
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
19
20
20
21
21
22
23
24
25
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
40
41
41
42
43
44
44
44
45
46
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 270067260 | 270067260 | Kit pilot lamp-indicator | |
| 270078960 | 270078960 | Dust protection cap | |
| 270102340 | 270102340 | comfort seat -Activo | |
| 270169450 | 270169450 | Safety belt Activo | |
| 270174800 | 270174800 | Connecting plate steering column | |
| 270174790 | 270174790 | Steering column panel bottom rh. | |
| 270174780 | 270174780 | Steering column panel bottom lh. | |
| 270174770 | 270174770 | Steering column panel centre top | |
| 270174760 | 270174760 | Steering column panel centre top | |
| 270174740 | 270174740 | Steering column panel top rh. | |
| 270174730 | 270174730 | Steering column panel top lh. | |
| 270174710 | 270174710 | Instrument carrier | |
| 270174690 | 270174690 | Steering column | |
| 270067280 | 270067280 | Kit pilot lamp-full beam | |
| 270067270 | 270067270 | Kit pilot lamp-green neutral | |
| 270174750 | 270174750 | Bellows rubber | |
| 1 | 270135190 | Steering column cpl. with headl. Flasher | |
| 2 | 270010350 | Seatbelt-optional | |
| 3 | 270065810 | Driver's seat | |
| 4 | 2200820 | Pedal guard | |
| 5 | 270102840 | Leather steering wheel 12 356mm | |
| 6 | 270108870 | Steering wheel cover cap | |
| 7 | 200275570 | Plating | |
| 8 | 270107210 | Valve 240/60 cm3/U -ltaly | |
| 9 | 9087580 | Locknut | |
| 10 | 2206270 | Steering valve adapter | |
| 11 | 2206280 | Rubber sheet-steering valve | |
| 12 | 9099070 | Detent edged washer | |
| 13 | 9031120 | Allen screw | |
| 14 | 9031111 | Allen screw | |
| 15 | 9006340 | Hex head bolt | |
| 16 | 9099091 | Detent edged washer | |
| 17 | 200279200 | Brake pedal | |
| 18 | 2325800 | Shaft | |
| 19 | 9349110 | Bearing bush | |
| 20 | 9105122 | Washer | |
| 21 | 9115221 | Circlip | |
| 22 | 200279190 | Support | |
| 23 | 2765841 | Tension spring | |
| 24 | 270074921 | Brake valve | |
| 25 | 9006170 | Hex head bolt | |
| 26 | 9087060 | Locknut | |
| 27 | 202204150 | Clamping lever | |
| 28 | 200274230 | Bottom part | |
| 29 | 200274200 | Adjustment | |
| 30 | 9006070 | Hex head bolt | |
| 31 | 900013800 | Detent edged washer | |
| 32 | 9104111 | Washer | |
| 33 | 200274270 | Retainer | |
| 34 | 202204130 | Coach bolt | |
| 35 | 202204140 | Clamping lever | |
| 36 | 9006160 | Hex head bolt | |
| 37 | 9099081 | Detent edged washer | |
| 38 | 9104130 | Washer | |
| 39 | 9082100 | Hex nut | |
| 40 | 9003640 | Hex head bolt | |
| 41 | 9082120 | Hex nut | |
| 42 | 200297110 | Rubber plate | |
| 43 | 9031111 | Allen screw | |
| 44 | 9104140 | Washer | |
| 45 | 900012300 | Locknut | |
| 46 | 202204120 | Rubber washer | |
| 47 | 270136720 | Steering-column switch |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
