Каталог запасных частей к технике: KRONE BIG-X-850-1. Discharge accelerator / bearing

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
202246350
202246350
202246350
202246350
1
2
2
3
3
3
3
4
4
5
5
5
5
5
5
6
6
7
7
8
8
9
9
9
9
10
10
11
11
12
12
13
14
15
16
16
16
16
17
18
19
19
20
21
21
22
23
24
25
25
26
26
27
28
29
30
31
32
33
34
35
36
36
36
36
37
37
38
38
39
39
40
40
41
42
43
Позиция на иллюстрации Заводской номер детали Название детали
202246350 202246350 Shim
1 9003520 Hex head bolt-left-hand thread
2 200263830 Cap
3 200245331 Lock collar
4 200215670 Pulley-disc corn conditioner
4 200245350 Pulley
5 9110051 Shim ring
5 9110040 Shim ring
6 200248031 Raceway outside Rd 80 x 27.5
7 202220450 Cover Rd 160
8 9030771 Allen screw
9 9099030 Detent edged washer
10 9360660 Radial-shaft sealing ring
11 900001930 Pendular roller bearing
12 9364472 Radial-shaft sealing ring
13 200260170 Bearing housing-right
14 9006570 Hex head bolt
15 9099101 Detent edged washer
16 200263880 Enclosure
17 200248000 Cover
18 9030731 Allen screw
19 200247990 Ball race
20 9150040 Fit-in key
21 200248521 Rotor
21 200263701 Rotor-HD optional
22 9047791 Coach bolt
23 2276802 Bushing
24 9087010 Locknut
25 200258600 Elevator paddle-right, by pairs
25 200231951 Elevator paddle-right, by pairs
26 200258590 Elevator paddle-left, by pairs
26 200231961 Elevator paddle-left, by pairs
27 9150180 Fit-in key
28 200263870 Ring
29 9059331 Threaded pin
30 200260120 Bearing housing-left
31 2141140 Thread block
32 9057671 Threaded pin
33 200248010 Receiver ring
34 200248041 Pulley
35 9021080 Hex head bolt
36 900004730 Allen screw
36 9031412 Allen screw
37 9099110 Detent edged washer
38 9006170 Hex head bolt
39 9099081 Detent edged washer
40 9106250 Washer
41 202222770 Scraper
42 9030781 Allen screw
43 202215050 Belt pulley 7 308mm-cracker drive-7 rills
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
