Каталог запасных частей к технике: KRONE BIG-X-850/1100. RockProtect

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
2
3
3
4
4
5
6
7
8
9
10
11
11
11
11
11
12
13
14
14
15
15
16
17
18
19
20
21
21
21
21
22
22
22
23
23
24
24
25
25
26
26
27
27
27
28
28
28
29
30
31
31
32
33
34
35
36
37
38
38
39
40
40
42
43
44
45
46
47
48
49
49
50
50
50
50
51
52
Позиция на иллюстрации Заводской номер детали Название детали
1 200806200 Job computer -without software
1 200809930 Job computer -incl. Software
2 200228390 Bracket
3 009087041 Locknut
4 009104111 Washer
5 009103511 Washer
6 270012060 Rubber pad
7 009011371 Hex head bolt
8 200805450 Y-Distributor-5-pole
9 009226711 Cable band
10 009034030 Allen screw
11 900000310 Tube clip w. rubber
11 009240610 Tube clip w. rubber
11 009240110 Tube clip w. rubber
12 009103070 Washer
13 009082040 Hex nut
14 009034271 Allen screw
14 900001900 Cylinder head-screw I-6kt M4 x 35 A3G
15 009103250 Washer
16 200804730 Accelerating transmitter
17 200235891 Bracket
18 009087180 Locknut
19 200805270 Connection cable-5-pole
20 200804763 CropControl cable harness 20X13
21 003022350 Protective grommet
22 003023530 Plug-4-pole
23 003029820 Blind-pin casing-4-pole
24 003034120 Valve plug-black , low mounting form
25 003021820 Screw with straight-line curls
26 003011860 Gasket
27 003023520 Plug-3-pole
28 003033790 Blind-pin casing-3-pole
29 200801720 Built-in socket-14-pole
30 003033480 Blind-plug
31 003024310 Plug-31-pole
32 200805321 Adapter wire
33 003023540 Coupling socket-4-pole
34 200804780 Wiring harness
35 003034140 Blind-plug
36 200801710 Plug-14-pole
37 200804863 Adapter wire
38 003020050 Connector plug-2-pole
39 003029830 Blind bushing casing-2-pole
40 003023560 Coupling socket-2-pole
42 003034010 Battery
43 200269870 Support
44 009099081 Detent edged washer
45 009006120 Hex head bolt
46 009006380 Hex head bolt
47 200270040 Spacer
48 200814530 Wiring harness
49 003033160 Plug-2-pole
50 003023620 Plug-42-pole
51 200814520 Wiring harness
52 202209000 Shim
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
