Каталог запасных частей к технике: KRONE BIG-X-700-1. Wear parts-driver's seat-activo

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Позиция на иллюстрации Заводской номер детали Название детали
270111480 270111480 Acc. susp. top part driver’s seat
270170340 270170340 Small part upholstery
270170440 270170440 Mount. parts lum. vert. supp. comf.-seat
270170390 270170390 Mounting parts cover comfort-seat
270170230 270170230 Small parts notch lever
270170390 270170390 Mounting parts cover comfort-seat
270170340 270170340 Small part upholstery
270170390 270170390 Mounting parts cover comfort-seat
270111420 270111420 Access. bellow driver’s seat
270170270 270170270 Small parts seat depth adjustment
270170390 270170390 Mounting parts cover comfort-seat
270170270 270170270 Small parts seat depth adjustment
270109780 270109780 Acc. compressor suspension
270111500 270111500 Access. conveyor belt comfort seat
270111400 270111400 Access. cover driver’s seat
270170290 270170290 Small part backrest
270170380 270170380 Mounting parts backrest
270170440 270170440 Mount. parts lum. vert. supp. comf.-seat
270077510 270077510 Mastic
270170440 270170440 Mount. parts lum. vert. supp. comf.-seat
270109790 270109790 Acc. shock absorber suspension
270170440 270170440 Mount. parts lum. vert. supp. comf.-seat
1 270111560 Rocker seat switch comf. seat
2 270111730 Blister cpl. comfort seat
3 270111740 Distribution climatisation comfort seat
4 270111750 Plate cpl. comfort seat
5 270111640 Back cpl. comfort seat
6 270111590 Rear bearing rh. cpl. driver’s seat
7 270111630 Seat plate driver’s seat
8 270111600 Stop backrest comfort seat
9 270111650 Seat cushion incl. adj. comfort seat
10 270111700 Seat depth adjustment comfort seat
11 270111680 Screening driver’s seat
12 270111690 Cover
13 270111670 Spring plate cpl. driver’s seat
14 270111660 Lever
15 270111760 Activation lum. vert. supp. Comfort seat
16 270109710 Ajdustment insert
17 270111720 Handle for DV comfort seat
18 270111520 Upholstery comfort seat
19 270111580 Handle for DA/HV/RLV KP comf. Seat
20 270111620 Handle support cpl. comfort seat
21 270111610 Cover lh. cpl. comfort seat
22 270111510 Upholstery comf. seat
23 270109720 Cable harness cpl. FS
24 270111180 Seat switch mit magnet
25 270111410 Bellow cpl. comfort seat
26 270109730 Cable harness cpl. FS
27 270111470 Susp. top part cpl. comfort seat
28 270109750 Cable harness cpl. FS
29 270111710 Cover cpl. comfort seat
30 270109770 Compr. 12V cpl. suspension
31 270111490 Conveyor belt comfort seat
32 270109760 Suspension MSG95 EL
33 270111380 Cover cpl. seat
34 270111540 Bowden cable cpl. comfort seat
35 270109700 Headrest cloth with logo
36 270111570 Backrest adjustment comfort seat
37 270109740 Level control seat
38 270077340 Shock absorber
39 270170350 Fan comfort-seat
40 270170420 Activation seat adjustment comfort-seat
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
