Каталог запасных частей к технике: KRONE BIG-X-650. Control box / controls eletronic

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
9
9
10
10
12
12
12
15
16
16
17
18
18
19
19
20
20
20
21
21
21
22
22
23
24
25
26
27
28
29
30
31
31
32
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
34
34
34
35
35
36
36
38
39
40
41
41
42
42
43
43
44
45
46
47
48
49
49
49
49
50
51
52
53
53
53
53
53
54
55
56
57
58
59
60
60
61
61
Позиция на иллюстрации Заводской номер детали Название детали
200803180 200803180 GAL-module-incl. software
1 002208001 Control box-cpl.
2 002208101 Substructure-panel
3 002208250 Maintenance door
4 270000740 Locking spigot
5 270000760 Retaining washer
6 270000750 Cam-lock
9 009099081 Detent edged washer
10 009006120 Hex head bolt
12 009087041 Locknut
15 200803160 Travel control-incl. software
16 270001310 Quick coupler
17 002208110 Retainer
18 270001320 Circlip
19 270001330 Quick coupler
20 009080061 Hex nut
21 009100010 Spring washer
22 200203190 Mat-Rubber
23 009030431 Allen screw
24 200803090 Automatic pilot-incl. software
25 002208130 Retainer
26 003039880 Diom exit-module
27 009034240 Allen screw
28 002208201 Retainer
29 200203180 Mat-Rubber
30 002208040 Metal sheet
31 009242020 Rubber pad
32 003039651 Relay board-cpl.
33 003021960 Flat fuse
33 003032010 Flat fuse
33 003018560 Flat fuse
33 003020760 Flat fuse
33 003020740 Flat fuse
33 003021940 Flat fuse
33 003031980 Flat fuse
33 003019770 Flat fuse
34 009103250 Washer
35 009034220 Allen screw
36 200803360 Distributor circuit board-CAN
38 200800111 Potential distributor circuit board
39 200808020 Job computer-incl. Software-cpl.
40
41 009036520 Allen screw
42 009100310 Spring washer
43 009082071 Hex nut
44 003025830 Bracket
45 003025840 Bracket
46 200808010 Job computer-incl. Software-cpl.
47 200216150 Holding plate
48 200216140 Supporting angle
49 009099061 Detent edged washer
50 009030431 Allen screw
51 009069480 Self-tapping screw
52 009226711 Cable band
53 009240100 Tube clip w. rubber
53 900000310 Tube clip w. rubber
53 009240610 Tube clip w. rubber
54 009251560 Edge protection-Id.-no.= 1m-black
55 200216170 Packing strip
56 270012060 Rubber pad
57 200228590 Top hat rail
58 009068110 Slotted pan head screw
59 200236570 Strut
60 009006060 Hex head bolt
61 003034010 Battery
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
