P.T.O shafts-roller gear-below
Warning signs
General information labels
Label- Circuit board
1
11
12
12
13
21
21
22
22
24
25
26
27
Позиция на иллюстрации
Заводской номер детали
Название детали
1
009560961
Pto drive shaft
11
009494771
Outer yoke
12
009492880
Locking pin
13
009554600
Outer yoke
21
009554061
Cross assy
22
009191080
Grease niple
24
009554610
Grooved yoke
25
009127242
Roll pin
26
009499950
Profile shaft
27
009554620
Yoke
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
