Каталог запасных частей к технике: KRONE BIG-X-650. Hydraulics- pump/storage chorging valve

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
9
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
29
30
31
32
33
34
35
36
37
38
38
39
39
40
41
41
42
43
43
44
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Позиция на иллюстрации Заводской номер детали Название детали
009190700 009190700 Solenoid coil
1 009192260 Pump-3 times
2 009099101 Detent edged washer
3 009006560 Hex head bolt
4 009115100 Circlip
5 002223162 Adapter
6 009376111 O-ring
7 009375050 O-ring
8 002286601 Connecting flange
9 009099081 Detent edged washer
10 009010461 Hex head bolt
10 009014250 Hex head bolt
11 009211741 Male connector
12 200242140 Hydraulic line-incl. nozzle disc cap, cutting ring
13 009191700 High pressure filter
14 009200870 High pressure hose line
15 009211831 Cutting ring
16 009211820 Nozzle disc cap
17 200242150 Hydraulic line-incl. nozzle disc cap, cutting ring
18 009211700 Connector
19 200242160 Hydraulic line-incl. nozzle disc cap, cutting ring
20 002296050 Storage charging valve
21 003020230 Pressure switch
22 009210602 Male connector
23 200206990 Hydraulic line-incl. nozzle disc cap, cutting ring
24 009210771 T-connector
25 009209011 Male connector
26 009085441 Hex nut-low form
27 009212390 Pressure accumulator
28 200217480 Hydraulic line-incl. nozzle disc cap, cutting ring
29 009199181 Male connector
30 009190340 3/2-Diverter vave bloc
31 009190280 3/2-Directional-control valve
32 200238530 Hydraulic line-incl. nozzle disc cap, cutting ring
33 009212060 Nozzle disc cap
34 009210461 Cutting ring
35 009010421 Hex head bolt
36 009251340 Cover plate
37 009251580 Tube clamp-2 halves
38 009211440 Male connector
39 009211750 T-connector
40 270003310 High pressure hose line
41 009196960 Connector f.mini-test equipm.
42 200239310 Valve holder
43 009087041 Locknut
44 009103511 Washer
45 009014100 Hex head bolt
46 009087580 Locknut
47 009099091 Detent edged washer
48 009006340 Hex head bolt
49 009212380 Adjustable L connection
50 009209020 Reducer fitting
51 270003730 Elbow-optional
52 270025390 Pressure control valve
53 200239240 Hydraulic line-incl. nozzle disc cap, cutting ring
54 009199240 Reducer fitting
55 009208270 Adjustable L connection
56 200239230 Line support
57 009251071 Tube clamp-2 halves
58 009030491 Allen screw
59 270083020 Sealing set
60 270037700 Sealing set
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
