Каталог запасных частей к технике: KRONE BIG-X-580. Hydraulics - discharge chute

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2
2
3
4
5
5
5
6
6
7
7
8
9
11
12
12
12
13
14
14
15
16
17
18
19
20
20
21
21
22
22
22
23
24
25
25
26
27
28
29
29
30
31
32
33
34
35
36
37
37
38
39
40
40
41
42
43
43
44
44
45
45
46
46
47
47
48
49
50
51
51
52
52
Позиция на иллюстрации Заводской номер детали Название детали
270120360 270120360 Gasket set
009188240 009188240 Sealing set
009185430 009185430 Hydraulic cylinder
270120440 270120440 O-ring seal
270196670 270196670 Gasket set
270010060 270010060 High pressure hose line
270142140 270142140 Hyd. hose
1 900000480 Male connector
2 009199670 Adjustable L connection
3 202227242 Hyd. line
4 270142120 Hyd. hose
5 009085060 Hex nut-low form
6 009199660 Connector
7 270010050 High pressure hose line
8 270010060 High pressure hose line
9 270186950 Hydraulic cylinder
11 270125170 Hyd. hose
12 009193020 Connector
13 202227181 Hyd. line
14 900015500 Мale connector
15 202227161 Hyd. line
16 270142110 Hyd. hose
17 009199630 Straight 2-way connector
18 270193990 Hyd. hose
18 270122950 Hyd. hose
19 202237510 Hyd. line
20 270105320 Screw coupl. plug
21 270105330 Protective cap sleeve
22 270123980 Hyd. hose
22 270123120 Hyd. hose
22 270134760 Hyd. Hose
23 270095952 Hydraulic cylinder
24 202237520 Hyd. line
25 270006620 Connector f.mini-test equipm.
26 202276561 Hose marking 2
27 202276541 Hose marking
28 009006140 Hex head bolt
29 009099081 Detent edged washer
30 009106030 Washer
31 202258241 Support hyd. lines
32 009010421 Hex head bolt
32 009010481 Hex head bolt
32 009010542 Hex head bolt
33 009251340 Cover plate
34 270078280 Tube clamp-2 halves
34 009251590 Tube clamp-2 halves
34 009251600 Tube clamp-2 halves
35 009104130 Washer
36 009087060 Locknut
37 009209011 Male connector
38 204203580 Hyd. line
39 204203590 Hyd. line
40 009199181 Male connector
41 270165790 Lowering brake valve
42 009210671 Angle lug
43 009196750 Male connector
44 009210871 Straight 2-way connector
45 009085242 Hex nut-low form
46 009200950 High pressure hose line
47 009196021 Male connector
48 009212790 Hydraulic motor
49 009211570 Protecting cap red
50 009211580 Plastic cap red
51 900032580 Disc
52 900026350 Angle bracket w dir. sett.
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
