Каталог запасных частей к технике: KRONE BIG-X-530. Grass channel / grain conditioner cpl.

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано 280CV-Q, 320CV-Q, 280CRI-Q (2013) 280CV-Q, 320CV-Q, 280CRI-Q (2013) ActiveMow R200 (2018) ActiveMow R200 (2018) ActiveMow R200 (2018) ActiveMow R200 (2018) ActiveMow R200 (2018) ActiveMow R200 (2018) ActiveMow R240 (2018) ActiveMow R240 (2018) ActiveMow R240 (2018) ActiveMow R240 (2018) ActiveMow R240 (2018) ActiveMow R240 (2018) ActiveMow R280 (2018) ActiveMow R280 (2018) ActiveMow R280 (2018) ActiveMow R280 (2018) ActiveMow R280 (2018) ActiveMow R280 (2018) ActiveMow R320 (2018) ActiveMow R320 (2018) ActiveMow R320 (2018) ActiveMow R320 (2018) ActiveMow R320 (2018) ActiveMow R320 (2018) ActiveMow R360 (2018) ActiveMow R360 (2018) ActiveMow R360 (2018) ActiveMow R360 (2018) ActiveMow R360 (2018) ActiveMow R360 (2018) AFL243RS (2013) AM 203CV, AM 243CV, AM 283CV (2018) AM 203CV, AM 243CV, AM 283CV (2018) AM 203CV, AM243CV, AM283CV (2018) AM 203CV, AM243CV, AM283CV (2018) AM 243 (2018) AM 243CV (2018) AM 243CV (2018) AM 243CV, AM283CV (2018) AM 283 (2018) AM 283CV (2018) BiG X 500 (2018) BiG X V8, BiG X V12 (2018) BIG-M-400 (2016) BIG-M-420 (2016) BIG-M-420 (2016) BIG-M-I (2016) BIG-M-I (2016) BIG-M-I (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-M-II (2016) BIG-X-1000 (2016) BIG-X-1000 (2016) BIG-X-1100 (2016) BIG-X-480 (2016) BIG-X-480 (2017) BIG-X-500 (2010) BIG-X-500 (2010) BIG-X-500 (2010) BIG-X-500 (2010) BIG-X-500 (2010) BIG-X-530 (2016) BIG-X-530 (2017) BIG-X-580 (2016) BIG-X-580 (2017) BIG-X-600 (2016) BIG-X-600 (2016) BIG-X-600 (2016) BIG-X-630 (2016) BIG-X-630 (2017) BIG-X-650 (2010) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-650 (2013) BIG-X-700 (2010) BIG-X-700 (2013) BIG-X-700 (2013) BIG-X-700-1 (2013) BIG-X-700-1 (2013) BIG-X-700-1 (2016) BIG-X-700-1 (2016) BIG-X-700-1 (2016) BIG-X-800 (2016) BIG-X-800 (2016) BIG-X-800/1000 (2013) BIG-X-850-1 (2018) BIG-X-850-1/1100-1 (2013) BIG-X-850-1/1100-1 (2013) BIG-X-850/1100 (2013) BIG-X-V8/BIG-X-V12 (2013) BIG-X-V8/BIG-X-V12 (2013) BIG-X-V8/BIG-X-V12 (2013) Easycollect (2018) EasyCut F360M (2018) EasyFlow 300, 380 (2012) EasyFlow 3000, 3800 (2013) EasyFlow 3000, 3800 (2013) EasyFlow 3001 (2013) EasyFlow 3001 (2013) EasyFlow 3001 (2013) EasyFlow 3001 (2013) EasyFlow 3001 (2013) EasyFlow 3001 (2013) EasyFlow 3801 (2013) EasyFlow 3801 (2013) EasyFlow 3801 (2013) EasyFlow 3801 (2013) EasyFlow 3801 (2013) EC 27/32 (2013) EC 28/32 (2013) EC 28/32 (2013) EC 28/32 (2013) EC 28/32CV (2013) EC 28/32CV (2013) EC 28/32CV (2013) EC 28/32M (2013) EC 28/32M (2013) EC 28/32P (2013) EC 28/32P (2013) EC 28/32P (2013) EC 28M (2013) EC 32CRI (2013) EC 32CRI (2013) EC 32CRI (2013) EC 32CV (2013) EC 360/400 (2013) EC 360/400 (2013) EC 360/400 (2013) EC 360/400 (2013) EC F280 (2018) EC F280 / F320 (2013) EC F280 M (2013) EC F280/320/360 (2013) EC F320 (2018) EC F320 M (2013) EC F320 M (2013) EC F320CV (2013) EC F320M/F360M (2013) EC F360 (2018) EC R280 (2013) EC R320 (2013) EC R360 (2013) EC R400 (2018) EC-9000 (2008) EC270CV/320CV (2013) EC280/320 (2013) EC280/320 (2013) EC280/320 (2013) EC280CV-Q/320CV-Q (2013) EC280CV/320CV (2013) EC280CV/320CV/280CR (2013) EC280CV/320CV/C280CRI (2013) EC28CV/32CV/32CV-F (2013) EC28CV/C32CV/32CV-F (2013) EC32CV/32CV-F (2013) EColl.6000,7500,6000FP (2013) EColl.6000,7500,9000,6000F (2013) EColl.6000,7500,9000,6000F/FP (2013) EColl.6000,7500,9000,6000F/FP (2013) EColl.6000-7500-9000-6000CL/JD (2013) ECollect 753, 903, 1053 (2013) ECollect753, 903, 1053 (2013) ECollect753, 903, 1053 (2013) ECR280CV/320CV (2012) KW 8.50-8 (2018) KWT 7.70-6X7, KWT 8.50-8, KWT 10.50-8X7 (2018) X-Disc 6200 (2013) X-Disc 6200 (2013)

Схема > Не выбрано Feeder Feeder Housing Wearing plates / guide - feeder Housing Grain collecting plate / slotted cover Cover- Feeder Housing Top feed rollers Top feed roller bearing Oscillating levers/Tension spring Lower feed rollers Lower feed roller bearing Drive - feed rollers Angle gear Roller gear below Top roller gearbox P.T.O shafts Pto drive shaft P.T.O shafts Pto drive shaft Double universal joint Double universal joint Pendulum equalizer PTO shaft coupler P.T.O shafts Pto drive shaft Chopping aggregate -cpl. without blades Chopping drum support Chopping drum support - mounting parts Chopping drum bearing / counter bearing Angle sensor - chopping drum Shear bar adjustment Sharpening Sharpening device drive Drum base -spring-mounted Chopping drum - 20 Knifes Chopping drum - 28 Knifes Chopping drum - 36 Knifes Grass channel / grain conditioner cpl. Cracker housing - mounting parts Spring - cracker housing Roller front Roller back Mounting aid corn conditioner 847800 - 905000 Mounting aid corn conditioner 905001 - 932000 Transfer channel Swivelling device Channel union -below Channel union -top Auger-gearbox Discharge accelerator / bearing Rotor Discharge accelerator housinge Rear panel 847800 - 932000 Rear panel 847800 - 932000 Upper discharge chute with wear plates Discharge flap-end piece -8 rows Discharge flap-end piece -CAL Diesel engine-BIG X 480 Accessories - diesel engine -BIG X 480 Diesel engine-BIG X 580 Accessories - diesel engine -BIG X 580 Charge air cooler Air cleaning equipment Radiator for motor fluid Exhaust gas equipment Accessories - exhaust gas equipment 847800 - 905000 Accessories - exhaust gas equipment 905001 - 932000 Mounting parts - engine Compressed air system Water compensation Pre-Cleaner Diesel fuel tank Diesel fuel tank -bonded rubber plate Auxiliary tank Mounting material without additional tank SCR tank Diesel fuel pipe Front attachment drive Auxiliary gearbox Mounting parts - intermediate gearbox Intermediate gearbox Transmission gear Drive engine-fan Power takeoff Main belt -back Clamping unit -back (main coupling) Main belt -front Clamping unit -front Belt drive corn conditioner Ventilator Fan gearbox Sieve Radiator door Sieve drum drive Radiator set Cooler housing Rotor Mounting parts - cooler housing Gear oil cooler Heating hose Air conditioning Main frame Bumper Battery box Steering axle Steering angle sensor Cabin holder Tyres -front Tyres -back Cab - control panel (roof) Cab - roof Cab - roof Cab - rear blind Cab - glazing Cab - glass wiper Cab - Sound deadening Cab - evaporator / filter Cab - evaporator Cab - frame / mounting parts Steering columm Wear parts - driver's seat -standard and activo Wear parts - driver's seat -standard Wear parts - driver's seat -activo Cab - terminal / armrest Cab - console 847800 - 906000 Cab - console 906001 - 932000 Cab - rear covering / passenger seat Cab - drawer Hydraulic tank High pressure circuit - two-wheel drive Variable disqlacement pump Charge pressure circuit Return lines - two-wheel drive 847800 - 932000 Return lines - two-wheel drive 847800 - 932000 Suction line Parts - two-wheel drive High pressure circuit - four-wheel drive Return lines - four-wheel drive HP line hydraulic system HP line hydraulic system Variable disqlacement pump Variable disqlacement pump Suction lines / charge pressure lines Suction lines / charge pressure lines Hydraulic panel Hydraulic main block Hydraulics - control bloc Hydraulic panel / pressure accumulator Hydraulics - pressure lines / pump Hydraulics - pressure lines -front Hydraulics - pressure lines -back Hydraulics - clamping unit -front/back Hydraulics - brake / gearbox Hydraulics - axle level Hydraulics - lift Hydraulics - sieve drive Hydraulics - steering Hydraulics - pressure lines -front attachment Hydraulics - front block Hydraulics - front block-(24V) Hydraulics - front attachment Hydraulics - unlock front attachment Hydraulics - brake front Hydraulics - brake rear Hydraulics - brake / brake valve Hydraulics - automatic steering Hydraulic block - automatic steering Hydraulics - swivelling device Hydraulics - discharge chute Hydraulics - discharge chute - 12/14-row Hydraulics - discharge chute - 12/14-row Hydraulics - pendulum equalizer Hydraulics - sharpening device Hydraulics - auxiliary tank Hydraulics - additive connection back Side flap Traction relief Cladding -front Cladding -front Back door Platform - right 847800 - 905000 Platform - right 905001 - 932000 Wheel well - front 847800 - 905000 Wheel well - front 905001 - 932000 Cab access - left 847800 - 905000 Cab access - left 905001 - 932000 Roof Seal cooling chamber Mudguard Panelling frame Kinematics lateral flaps Warning panel 905001 - 932000 Warning panel 847800 - 932000 Warning panel 847800 - 932000 Wiring harness - right front Wiring harness - centre Wiring Harness - engine Wiring harness - back left Wiring harness - left front Wiring harness - KMB 2 Wiring Harness - rear Wiring harness - hydraulic panel Wiring harness - SCR system Wiring Harness - feeder Wiring Harness - chopping aggregate Wiring Harness - back door Wiring harness - below the cabin Wiring loom - cab Wiring harness - panel Wiring Harness - Headlight Wiring Harness - cab access Wiring Harness - ladder lighting Wiring Harness - journal Wiring Harness - KMB 4 Wiring Harness - KMB 3 Wiring Harness - Discharge chute extension 12/14-row Several wiring looms Battery and ground cable Electronics Camera surveillance Wiring harness fastening 847800 - 905000 Wiring harness fastening 905001 - 932000 Wiring harness fastening 847800 - 932000 Lighting Central lubrication Pump for central lubrication Spare parts case for central lubrication -BEKA MAX Warning signs General information labels Silage agent system 847800 - 932000 Silage agent system 847800 - 932000 Friction base CropControl RockProtect Husk Additional axis Hydraulics - additional axis Rope winch / additional axis ForageCam NIR - Moisture measurement Maintenance lighting ISOBUS Preparation for silage additive system Headlight - LED -optional Lighting Installation car - feeder Installation car - chopping drum Additional weights Discharge flap-end piece -10 rows Discharge chute extension 12/14-row Discharge flap-end piece -12/14 rows Enclosed parts Filter element Wearing plates - crop flow

1

2

3

3

3

4

5

6

7

8

8

9

10

11

Позиция на иллюстрации	Заводской номер детали		Название детали
009002790	009002790		Hex head bolt
200291504	200291504		Grass slot trail
1	204213860		Corn conditioner with roller 105 T. HD
1	202243371		Corn conditioner 123 teeth assem.
1	202243401		Corn conditioner 123 teeth HD-V assem.
1	202243460		Corn conditioner 123 teeth HD-V 30% asse
1	202243341		Corn conditioner 144 teeth assem.
1	202243410		Corn conditioner 144 teeth HD-V assem.
1	202243430		Corn conditioner 105 teeth assem.
2	202243391		Corn conditioner 166 teeth assem.
3	009099091		Detent edged washer
4	202275890		Wear plate
5	202255560		Wear plate HD
6	200299021		Stop
7	009006370		Hex head bolt
8	009103530		Washer
9	009087580		Locknut
10	202254262		Bearing plate
11	900024120		Countersunk screw square

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
