Каталог запасных частей к технике: KRONE BIG-X-530. High pressure circuit - four-wheel drive

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
3
4
5
6
7
8
9
10
10
10
10
10
10
10
10
10
10
11
11
12
13
13
14
14
15
16
16
17
18
19
20
20
21
21
22
23
24
25
26
27
27
28
29
29
Позиция на иллюстрации Заводской номер детали Название детали
900021870 900021870 O-ring seal 235 х 3
200836610 200836610 Braided sleeving
900030580 900030580 Locking screw hexa. socket
270099320 270099320 Prop. magnet witho. em. act.
270103090 270103090 Gasket set power unit
270103080 270103080 Flush valve
900030580 900030580 Locking screw hexa. socket
270099320 270099320 Prop. magnet witho. em. act.
270103090 270103090 Gasket set power unit
270103080 270103080 Flush valve
900021880 900021880 O-ring seal 150 х 4
270202230 270202230 Disc
900027940 900027940 Locking screw inside hexagon
009450910 009450910 Gasket ring
270202220 270202220 flat gasket
1 270080520 Hub gearboх
2 270100260 0il 0l SYNKR0L Shell Spiraх S4 CХ 50
3 270100270 0il 0l SYNShell Spiraх S4 CХ 50 20L
4 270104950 Lable
5 009099121 Detent edged washer
6 009006770 Hex head bolt
7 270133260 Adjusting motor
8 200833860 Rotational speed sensor assembl.
9 270133270 Adjusting motor
10 900019020 O-ring
11 202200162 Flange adapter rear
12 009404780 Spiral strip-Id.-no.= 1m
13 270122901 Hyd hose
14 270109161 Hydr. hose
15 009014391 Hex head bolt
16 009104140 Washer
17 009251251 Cover plate
18 009251541 Tube clamp-2 halves
19 202237130 Holder right
20 009099091 Detent edged washer
21 009087580 Locknut
22 202237110 Support
23 009006370 Hex head bolt
24 900019050 Allen screw
25 900024060 Cylinder screw hexagon socket
26 009226711 Cable band
27 202271470 Rotational speed sensor assembl.
28 900026820 Hexagon head screw
29 202237241 Mounting ring wheel mounting rear
