Каталог запасных частей к технике: KRONE BiG X 500. Several wiring looms

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
20 080 106 0
1
2
2
2
3
3
4
4
5
6
7
8
9
10
11
11
12
13
14
14
14
14
15
15
16
17
18
19
20
21
21
22
23
24
24
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
40
41
Позиция на иллюстрации Заводской номер детали Название детали
20 080 106 0 20 080 106 0 Wiring harness -short
1 00 305 032 0 Wiring harness -oil tank
2 00 303 084 0 Plug -10-pole
3 00 305 059 0 Plug -2-pole
4 00 302 688 0 Flat sleeve -red
5 00 303 116 0 AMP-circular plug -4-pole
6 20 080 038 1 Wiring harness -rope winch /electronics cab
7 00 303 674 0 Plug
8 20 083 941 0 Extension
9 20 083 940 0 Extension
10 00 303 172 2 Adapter
11 00 302 354 0 Coupling socket -4-pole
12 00 303 227 2 Adapter
13 20 083 695 0 Y-distributor M12x1 -5-pole
14 00 924 069 0 Screwless corrugatend tube
14 00 924 071 0 Screwless corrugatend tube
14 00 924 070 0 Screwless corrugatend tube
14 00 924 068 0 Screwless corrugatend tube
15 00 924 061 0 Tube clip w. rubber
15 00 924 062 0 Tube clip w. rubber
16 20 080 003 2 Wiring harness -feed system
17 00 302 352 0 Plug -3-pole
18 20 082 583 1 Plug 14-p Bu silver -14-pole
19 00 303 414 0 Blind-plug
20 00 303 186 2 Wiring harness -chute extension
21 00 303 073 0 Bushing housing -10-pole
22 20 080 045 2 CH discharge chute elbow
23 00 302 431 1 Plug
24 00 302 356 0 Coupling socket -2-pole
25 00 303 171 3 Wiring harness -discharge chute
26 00 303 120 0 Plug -2-pole
27 00 302 921 0 Concluding stop-light
28 00 924 693 0 Singel filament buld
29 00 924 709 0 Singel filament buld
30 00 221 071 0 Grooming switch
31 00 302 510 1 Levelling switch
32 00 229 710 0 Pressure switch
33 00 940 109 1 Pressure switch
34 00 303 146 0 Hall sensor
35 00 303 413 0 Blind-plug
36 00 303 348 0 Blind-plug
37 20 080 760 0 Pane
38 20 080 815 0 Wiring harness
39 00 301 988 0 Valve plug with LED
40 00 302 182 0 Screw with straight-line curls
41 00 301 186 0 Gasket
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
