Каталог запасных частей к технике: KRONE BIG-X-480. High pressure circuit - two-wheel drive

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2
2
3
3
4
4
4
5
6
7
8
9
9
10
11
11
12
12
12
12
12
12
12
12
13
13
14
14
15
16
17
18
19
20
20
21
21
21
21
22
22
23
24
24
25
26
27
28
29
29
29
29
30
31
31
31
31
32
33
34
35
36
37
37
37
37
38
39
40
40
41
42
43
44
45
46
46
47
47
48
49
50
51
52
52
53
Позиция на иллюстрации Заводской номер детали Название детали
900021860 900021860 O-ring seal 310 х 3
270103050 270103050 Flush valve
270103070 270103070 Gasket set power unit
270099320 270099320 Prop. magnet witho. em. act.
270103050 270103050 Flush valve
270103070 270103070 Gasket set power unit
270099320 270099320 Prop. magnet witho. em. act.
900030580 900030580 Locking screw hexa. socket
900021850 900021850 O-ring seal 192 х 4
900030580 900030580 Locking screw hexa. socket
900027940 900027940 Locking screw inside hexagon
009450910 009450910 Gasket ring
900027950 900027950 Locking screw inside hexagon
009377110 009377110 Gasket ring
270045720 270045720 Spiral strip-Id.-no.=1m
202237271 202237271 Mounting ring wheel mounting front
900026810 900026810 Hexagon head screw
1 270089790 Variable displac. pump
2 900019040 O-ring
3 270137591 Pressure sensor
4 900019070 Allen screw
5 270122460 Hyd. hose
6 270122470 Hyd. hose
7 009003470 Hex head bolt
8 009104140 Washer
9 202200392 Distribution block
10 009099091 Detent edged washer
11 009087580 Locknut
12 900019030 O-ring
13 270100260 0il 0l SYNKR0L Shell Spiraх S4 CХ 50
14 900019060 Allen screw
15 270119470 Hyd. hose
16 270119480 Hyd. hose
17 270119460 Hyd. hose
18 270119450 Hyd. hose
19 202234722 Support traction drive hose right
20 009106030 Washer
21 009099081 Detent edged washer
22 009006160 Hex head bolt
23 202234695 Support traction drive hose lh
24 270080320 Tube clamp -2 halves
25 270058550 Cover plate
26 009010491 Hex head bolt
27 202200380 Flange adapter right
28 009031452 Allen screw
29 270039240 Flange gasket
30 202200351 Flange adapter front right
31 900029030 Locking screw A hexag. G 1dm E
32 270133290 Adjusting motor
33 202200360 Flange adapter left
34 202200340 Flange adapter front left
35 200833860 Rotational speed sensor assembl.
36 270133310 Adjusting motor
37 202202364 Screw-in slat
38 009014211 Hex head bolt
39 900024480 Spannhlse
40 202200423 Adapter
41 009015040 Heх head bolt
42 009099131 Detent edged washer
43 009003110 Hex head bolt
44 270104950 Lable
45 270100270 0il 0l SYNShell Spiraх S4 CХ 50 20L
46 270082452 Wheel hub gearbox with brake
47 200836610 Braided sleeving
48 009226711 Cable band
49 202271470 Rotational speed sensor assembl.
50 900002930 Allen screw
51 009104130 Washer
52 200278860 Мounting ring
53 900017490 Heх head bolt
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
