Каталог запасных частей к технике: KRONE BIG-X-480. Chopping drum bearing / counter bearing

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
10
11
12
12
13
14
15
16
17
17
17
18
19
20
20
21
22
23
23
24
24
25
25
25
25
26
26
27
27
28
29
29
29
30
30
31
32
33
34
34
35
35
36
37
38
39
40
41
42
43
44
45
46
46
47
49
50
Позиция на иллюстрации Заводской номер детали Название детали
900030130 900030130 Cylinder screw hexagon socket
1 270091951 V-belt pulley
2 200288071 Drum bearing bushing
3 200280092 Frame bearing
4 009087210 Locknut
5 009099131 Detent edged washer
6 002143310 End plate
7 200281192 Arrester
8 009030731 Allen screw
9 009099030 Detent edged washer
10 202211361 Holding plate
11 202211371 Support
12 009106030 Washer
13 009104130 Washer
14 009006140 Hex head bolt
15 003034691 Namur sensor Namur
16 200288081 Slide ring
17 009116960 Circlip
18 200288021 O-ring seal
19 009360500 Radial-shaft sealing ring
20 009319200 Pendular roller bearing
21 002142810 Thrust ring
22 200238032 Bearing housing left
23 900017410 Threaded pin
24 009006770 Hex head bolt
25 009099121 Detent edged washer
26 009360670 Radial-shaft sealing ring
27 002142800 Intermediate ring
28 009116940 Circlip
29 009006740 Hex head bolt
29 009006770 Hex head bolt
30 202215241 Line support
31 200287651 Threaded ring left
32 200288101 Threaded ring right
33 009116910 Circlip
34 002241282 Intermediate washer
35 009360610 Radial-shaft sealing ring
36 200280053 Bearing housing right
37 002240301 Supporting disc
38 009115700 Circlip
39 202270521 Spacer bushing
40 009375340 O-ring
41 200298311 Cover
42 009191060 Grease niple
43 009006100 Hex head bolt
44 009099081 Detent edged washer
45 900019780 Shim ring
45 900019790 Shim ring
45 900019800 Shim ring
46 200283651 Support disc
47 009115400 Circlip
49 900017080 Fit-in key
50 270152880 Taper bushing
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
