Working hydraulics - valve "freinage"
Каталог запасных частей к технике: KRONE BIG-M-I. Working hydraulics - valve "freinage"
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
AGCO
Amity
CASE IH
DongFeng
Fortschritt
Foton
Franz Kleine
Gaspardo
Great Plains
KRONE
KUHN
Lemken
Lovol
MacDon
Massey Ferguson
New Holland
TIGARBO
Vaderstad
Versatile
Wirax
Агро
Агротехмаш
Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш»)
БЭМЗ
ВгТЗ
Воронежсельмаш
ВТЗ
Гомсельмаш
ДКЗ
ЗАО "Техника-сервис"
ЗиД
КЗК
Кировец-Ландтехник
Клевер
Красная Звезда
Лидагропроммаш
Лидсельмаш
ЛТЗ
Машстройхолдинг
Минитракторы
Мордовагромаш
МТЗ
Навигатор-Новое машиностроение
Нефтекамский автозавод
ПТЗ
Ремком
РСМ
Сибсельмаш
ТеКЗ
ТКЗ
ХЗТСШ
ХТЗ
ЮМЗ
Модель
Не выбрано
280CV-Q, 320CV-Q, 280CRI-Q (2013)
280CV-Q, 320CV-Q, 280CRI-Q (2013)
ActiveMow R200 (2018)
ActiveMow R200 (2018)
ActiveMow R200 (2018)
ActiveMow R200 (2018)
ActiveMow R200 (2018)
ActiveMow R200 (2018)
ActiveMow R240 (2018)
ActiveMow R240 (2018)
ActiveMow R240 (2018)
ActiveMow R240 (2018)
ActiveMow R240 (2018)
ActiveMow R240 (2018)
ActiveMow R280 (2018)
ActiveMow R280 (2018)
ActiveMow R280 (2018)
ActiveMow R280 (2018)
ActiveMow R280 (2018)
ActiveMow R280 (2018)
ActiveMow R320 (2018)
ActiveMow R320 (2018)
ActiveMow R320 (2018)
ActiveMow R320 (2018)
ActiveMow R320 (2018)
ActiveMow R320 (2018)
ActiveMow R360 (2018)
ActiveMow R360 (2018)
ActiveMow R360 (2018)
ActiveMow R360 (2018)
ActiveMow R360 (2018)
ActiveMow R360 (2018)
AFL243RS (2013)
AM 203CV, AM 243CV, AM 283CV (2018)
AM 203CV, AM 243CV, AM 283CV (2018)
AM 203CV, AM243CV, AM283CV (2018)
AM 203CV, AM243CV, AM283CV (2018)
AM 243 (2018)
AM 243CV (2018)
AM 243CV (2018)
AM 243CV, AM283CV (2018)
AM 283 (2018)
AM 283CV (2018)
BiG X 500 (2018)
BiG X V8, BiG X V12 (2018)
BIG-M-400 (2016)
BIG-M-420 (2016)
BIG-M-420 (2016)
BIG-M-I (2016)
BIG-M-I (2016)
BIG-M-I (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-M-II (2016)
BIG-X-1000 (2016)
BIG-X-1000 (2016)
BIG-X-1100 (2016)
BIG-X-480 (2016)
BIG-X-480 (2017)
BIG-X-500 (2010)
BIG-X-500 (2010)
BIG-X-500 (2010)
BIG-X-500 (2010)
BIG-X-500 (2010)
BIG-X-530 (2016)
BIG-X-530 (2017)
BIG-X-580 (2016)
BIG-X-580 (2017)
BIG-X-600 (2016)
BIG-X-600 (2016)
BIG-X-600 (2016)
BIG-X-630 (2016)
BIG-X-630 (2017)
BIG-X-650 (2010)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-650 (2013)
BIG-X-700 (2010)
BIG-X-700 (2013)
BIG-X-700 (2013)
BIG-X-700-1 (2013)
BIG-X-700-1 (2013)
BIG-X-700-1 (2016)
BIG-X-700-1 (2016)
BIG-X-700-1 (2016)
BIG-X-800 (2016)
BIG-X-800 (2016)
BIG-X-800/1000 (2013)
BIG-X-850-1 (2018)
BIG-X-850-1/1100-1 (2013)
BIG-X-850-1/1100-1 (2013)
BIG-X-850/1100 (2013)
BIG-X-V8/BIG-X-V12 (2013)
BIG-X-V8/BIG-X-V12 (2013)
BIG-X-V8/BIG-X-V12 (2013)
Easycollect (2018)
EasyCut F360M (2018)
EasyFlow 300, 380 (2012)
EasyFlow 3000, 3800 (2013)
EasyFlow 3000, 3800 (2013)
EasyFlow 3001 (2013)
EasyFlow 3001 (2013)
EasyFlow 3001 (2013)
EasyFlow 3001 (2013)
EasyFlow 3001 (2013)
EasyFlow 3001 (2013)
EasyFlow 3801 (2013)
EasyFlow 3801 (2013)
EasyFlow 3801 (2013)
EasyFlow 3801 (2013)
EasyFlow 3801 (2013)
EC 27/32 (2013)
EC 28/32 (2013)
EC 28/32 (2013)
EC 28/32 (2013)
EC 28/32CV (2013)
EC 28/32CV (2013)
EC 28/32CV (2013)
EC 28/32M (2013)
EC 28/32M (2013)
EC 28/32P (2013)
EC 28/32P (2013)
EC 28/32P (2013)
EC 28M (2013)
EC 32CRI (2013)
EC 32CRI (2013)
EC 32CRI (2013)
EC 32CV (2013)
EC 360/400 (2013)
EC 360/400 (2013)
EC 360/400 (2013)
EC 360/400 (2013)
EC F280 (2018)
EC F280 / F320 (2013)
EC F280 M (2013)
EC F280/320/360 (2013)
EC F320 (2018)
EC F320 M (2013)
EC F320 M (2013)
EC F320CV (2013)
EC F320M/F360M (2013)
EC F360 (2018)
EC R280 (2013)
EC R320 (2013)
EC R360 (2013)
EC R400 (2018)
EC-9000 (2008)
EC270CV/320CV (2013)
EC280/320 (2013)
EC280/320 (2013)
EC280/320 (2013)
EC280CV-Q/320CV-Q (2013)
EC280CV/320CV (2013)
EC280CV/320CV/280CR (2013)
EC280CV/320CV/C280CRI (2013)
EC28CV/32CV/32CV-F (2013)
EC28CV/C32CV/32CV-F (2013)
EC32CV/32CV-F (2013)
EColl.6000,7500,6000FP (2013)
EColl.6000,7500,9000,6000F (2013)
EColl.6000,7500,9000,6000F/FP (2013)
EColl.6000,7500,9000,6000F/FP (2013)
EColl.6000-7500-9000-6000CL/JD (2013)
ECollect 753, 903, 1053 (2013)
ECollect753, 903, 1053 (2013)
ECollect753, 903, 1053 (2013)
ECR280CV/320CV (2012)
KW 8.50-8 (2018)
KWT 7.70-6X7, KWT 8.50-8, KWT 10.50-8X7 (2018)
X-Disc 6200 (2013)
X-Disc 6200 (2013)
Схема
>
Не выбрано
Cutter bar with bearings (CV + CRI)
Cutting bar with flange (CV + CRI)
Cutter bar with quick coupler (CV)
Cutter bar with blade fastening (CV)
Cutter bar with blade fastening (CRI)
Guide plate CRI
High-cut skid (CV + CRI)
Cover for main gear box (CV+CRI)
Main gearbox and driving shaft (CV+CRI)
Main gearbox and driven shaft (CV+CRI)
Guards gearbox (front) (CV) 398350 - 440099
Guards gearbox (CV+CRI) 440100 - 463489
Air level (CV+CRI)
Tine conditioner housing, assembled
Tine conditioner housing, assembled
Conditioner comb with accessories
Finger rotor, assembled
Lubricating line - grease (CV)
Tine conditioner drive
Guard for front mower beam (CV)
Guard for front mower beam lh (CV)
Guard for front mower beam rh (CV)
Roller conditioner housing, assembled 398350 - 463489
Roller conditioner housing, assembled 398350 - 463489
Rh rubber rollers
Lh rubber rollers
Oscillating levers
Lubricating line - grease (CRI)
Roller conditioner drive
Guard for front mower beam (CRI)
Guard for front mower beam lh (CRI)
Guard for front mower beam rh (CRI)
Frame
Steering axle installed
Tyres
Mudguard
Lighting bracket
Trailer hitch
Mounting parts for central gearbox
Central gearbox
Tensioning device on central gearbox
Tens. device on central gearbox front
Belt guard located on central gearbox
Belt gurd located on the rh side
Belt gurd located on the lh side
Rh wing arm
Lh wing arm
Universal joint support installed
Mounting parts number of mover units
Spring compensation
Front auxiliary pto.stub
Mounting for front arm (fixed)
Front arm installed (slope)
Mounting for front arm (slope)
Mount.parts front frame condit.housing
Cantilever
Clutch with accessories
Silencer assembled
Air filter installed
Compressor (air conditioner)
Fan drive
Radiator - Radiator frame
Cooler - cooling agent cooler
Radiator - oil cooler
Radiator - charge air cooler
Radiator - condenser for air conditioner
Suction
Cap platform with support
Box
Railing installed
Leader installed
Guard support front and back installed
Valve guard
Engine guards
Radiator guards
Battery guards
Diesel fuel tank
Inner panels - cab roof
Instrument console - cab roof
Control switsches
Radio accessories
Covers - interior light
Rear view mirror
Rear view mirror
Dash
Dash control switsches
Multiple indicators front-right-hand
Steering column - upper
Steering column - lower
Steering column - steering wheel shaft
Air conditioning
Cab heater components
Heating connection
Individual parts for steering
Air conditioning components
Cooling compartment components
Ventilations ducts
Filter box
Passenger seat
Air comfort seat
Cab suspension
Cab frame - Cab roof
Windshield washer
Window and lining , r.h.
Cab door
Windshield
Pedals and bracket (foot brakes)
Works/beacon light / horn
Parking brake
Unlocking device - parking brake
Speed control linkage
Multifunction lever
Hydraulic tank with filter
Mounting for hydraulic tank
Working hydraulics - valves frame
Working hydraulics - accum.charg.valves
Working hydraulics - valve block (3x)
3 diverter vave bloc
Working hydraulics - valve block
Working hydr. - hydr.line (steering)
Gear pump
Gear pump - 2 x
Working hydraulics - valve block (4 x)
4 diverter vave bloc
Working hydr. - Front connection part1
Working hydr. - Front connection part2
Working hydraulics - drive
Working hydraulics - hydraulic ram
Work hydraulics levell.-mechan.with ram
Working hydraulics - valve "freinage"
Brake line - front
Brake line - back
Hydr.ground drive/fin.drives
Hydr.ground drive/var.displ. pump
Hydr.ground drive - front
Hydr.ground drive/rear driving valve
Hydr.ground drive - rear
Hydr.ground drive/front leakage oil line
Hydr.ground drive/rear leakage oil line
Hydr.ground drive/pressure oil line - front
Hydr.ground drive/pressure oil line - rear
Hydr.ground drive
Connection cable
Wiring Harness 01 (engine)
Wiring harnes 02.01 (lighting bracket)
Wiring Harness 02.2 (Lighting rear)
Wiring Harness
Wiring Harness 07 (Lighting front)
Wiring Harness 08 (fan)
Wiring Harness
Wiring Harness 10 (cab)
Wiring Harness 10.2 440100 - 463489
Wiring Harness 11
Wiring Harness
Pedal - levelling mechanism
Main distributor
Job computer KMS
P.T.O shafts BYPY
Double universal joint DG 2400
Double universal joint Gr.5
P.T.O shafts WWZ-SFT 60-50 GR
Engine wearing parts
Warning signs
General information labels
1
2
3
3
4
5
6
6
7
7
8
9
10
11
12
13
14
Позиция на иллюстрации
Заводской номер детали
Название детали
1
009210160
High pressure hose line
2
009212581
High pressure hose line
3
009210602
Male connector
4
002296040
Brake valve
5
009210791
Adjustable L connection
6
009210461
Cutting ring
7
009212060
Nozzle disc cap
8
002307430
Double nipple
9
009209190
Connector
10
003020291
Рrеssurе trаnsfоrmеr
11
009030550
Allen screw
12
009251470
Tube clamp-2 halves
13
009087060
Locknut
14
009006170
Hex head bolt
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
