1
2
3
4
5
5
6
7
8
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
009040631
009040631
Countersunkscrew
1
002534960
Support
2
009040711
Countersunkscrew
3
009040653
Countersunkscrew
4
009099101
Detent edged washer
5
009087010
Locknut
6
001390802
Swath board-right
7
009049951
Coach bolt
8
00152421
Pressure spring
9
009106090
Washer
10
001399121
Support -left
11
001449851
Swath board -left
