Каталог запасных частей к технике: Great Plains 2S-2600, 2S-2600F. Dual Gauge Wheel
1
1
2
3
4
5
6
6
7
8
9
9
10
10
11
11
12
12
13
13
14
15
16
16
17
17
18
18
19
19
19
19
20
20
20
20
21
22
22
23
23
24
24
25
25
26
27
28
28
29
30
31
32
33
34
35
36
37
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 194-273D | TORSION SPRING HANDLE LH | |
| 1 | 194-274D | TORSION SPRING HANDLE RH | |
| 2 | 195-159D | SUBFRAME LOCK HOOK | |
| 3 | 802-138C | HHCS | |
| 4 | 195-160D | GAUGE WHEEL LOCK PIN | |
| 5 | 803-011C | NUT LOCK | |
| 6 | 803-208C | NUT BEARING LOCK | |
| 7 | 804-098C | WASHER BEARING LOCK | |
| 8 | 195-229D | SPNDLE | |
| 9 | 120-198D | AXLE SPACER TUBE | |
| 10 | 816-138C | SEAL DBL LIP | |
| 11 | 822-117C | BEARING CONE | |
| 12 | 822-118C | BEARING CUP | |
| 13 | 808-287C | SPKT | |
| 13 | 808-097C | SPKT | |
| 14 | 805-030C | PIN ROLL | |
| 15 | 816-012C | SEAL | |
| 16 | 802-104C | BOLT WHEEL | |
| 17 | 814-026C | TIRE | |
| 18 | 816-035C | VALVE STEM | |
| 19 | 814-540C | WHEEL | |
| 19 | 814-008C | WHEEL | |
| 20 | 161-046K | WHL&TIRE | |
| 20 | 161-026K | WHL&TIRE | |
| 21 | 816-241C | RUBBER HANDLE GRIP | |
| 22 | 152-390D | HEAVY DRIVE HUB | |
| 23 | 803-263C | NUT HEX FLANGE LOCK | |
| 24 | 804-095C | WASHER FLAT | |
| 25 | 802-640C | HHCS | |
| 26 | 818-751C | DECAL CAUTION TIRE | |
| 27 | 195-234D | WASHER FLAT | |
| 28 | 195-265D | SPNDL | |
| 28 | 195-351D | SPNDL | |
| 29 | 804-182C | WASHER HARD | |
| 30 | 803-239C | NUT HEX SLOTTED | |
| 31 | 805-148C | PIN COTTER | |
| 32 | 808-413C | SPKT | |
| 33 | 891-137C | HUB KEYLESS | |
| 34 | 195-352D | WRENCH OPEN END | |
| 35 | 195-355D | WRENCH SPANNER | |
| 36 | 195-398H | DRIVE SPROCKET TORQUING NUT | |
| 37 | 805-249C | PIN ROLL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
