Каталог запасных частей к технике: Great Plains 1200, 1500, 2000. Small Seeds Metering

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
4
5
6
7
8
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
10
11
11
12
13
13
14
14
14
15
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
31
32
33
34
Позиция на иллюстрации Заводской номер детали Название детали
1 809-115C #40 CHAIN 60 PITCH W/CON.
2 123-834H SML SDS DRIVE SPKT HUB
3 803-003C NYLOCK
4 804-007C WASHER FLAT
5 817-026C HANGER DRIVE SHAFT
6 804-044C WASHER FLAT
7 800-028C SNAP RING
8 802-005C HHCS
9 123-505D 3PT SML SDS 20'-6 CUP SHFT
9 123-514D 3PT SML SDS 12'-10 CUP SHFT
9 123-506D 3PT SML SDS 20'-7 CUP SHFT
9 123-507D 3PT SML SDS 20'-7.5 CUP SHFT
9 123-508D 3PT SML SDS 20'-8 CUP SHFT
9 123-509D 3PT SML SDS 20'-10 CUP SHFT
9 123-510D 3PT SML SDS 12'-6 CUP SHFT
9 123-511D 3PT SML SDS 12'-7 CUP SHFT
9 123-512D 3PT SML SDS 12'-7.5 CUP SHFT
9 123-513D 3PT SML SDS 12'-8 CUP SHFT
9 123-495D 3PT SML SDS 15'-6 CUP SHFT RH
9 123-504D 3PT SML SDS 15'-10CUP SHFT LH
9 123-496D 3PT SML SDS 15'-6 CUP SHFT LH
9 123-497D 3PT SML SDS 15'-7 CUP SHFT RH
9 123-498D 3PT SML SDS 15'-7 CUP SHFT LH
9 123-499D 3PT SMLSDS 15'-7.5CUP SHFT RH
9 123-500D 3PT SMLSDS 15'-7.5CUP SHFT LH
9 123-501D 3PT SML SDS 15'-8 CUP SHFT RH
9 123-502D 3PT SML SDS 15'-8 CUP SHFT LH
9 123-503D 3PT SML SDS 15'-10CUP SHFT RH
10 804-042C WASHER GRASS SEEDER CUP SHAFT
11 805-067C PIN COTTER
12 817-009C GRASS SEEDER SLEEVE
13 817-504C SML SEED FEEDER CUP ASSY
13 817-008C RPBY
14 803-006C NUT-HEX
15 817-010C GRASS SEEDER SPROCKET
16 802-148C HFSS
17 804-006C WASHER LOCK SPRING
18 123-050H ADJUSTMENT HANDLE PIVOT
19 805-019C PIN COTTER
20 890-349C SHAFT LOCKING COLLAR
20 123-436D RPBY 890-349C
21 801-035C SCREW SET
22 123-116D SEED ADJUSTMENT SPOOL
23 804-012C WASHER FLAT
24 123-476H REAR SEED RATE ADJ HANDLE WLD
25 803-058C NUT WING
26 123-113D LOCK TAB
27 802-092C RHSNB
28 123-410D GAUGE MOUNTING BRACKET
29 803-035C NUT HEX
30 804-002C WASHER INTERNAL STAR
31 804-003C WASHER FLAT
32 819-041C SEED ADJUSTMENT GUIDE
33 801-001C SCREW RD HD
34 817-806C SMALL SEEDS CUP WIND SHIELD
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
