Каталог запасных частей к технике: Great Plains 1200, 1500, 2000. Small Seeds Box & Lid Assembly
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
3
4
4
5
6
6
6
7
8
9
9
10
10
10
10
11
11
12
13
14
14
15
16
17
18
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 123-775H | 3PT 15'-6 SML SDS BOX RH | |
| 1 | 123-798H | 3PT 12'-10 SML SDS BOX | |
| 1 | 123-797H | 3PT 12'-8 SML SDS BOX | |
| 1 | 123-796H | 3PT 12'-7 1/2 SML SDS BOX | |
| 1 | 123-795H | 3PT 12'-7 SML SDS BOX | |
| 1 | 123-794H | 3PT 12'-6 SML SDS BOX | |
| 1 | 123-793H | 3PT 20'-10 SML SDS BOX RH | |
| 1 | 123-792H | 3PT 20'-10 SML SDS BOX LH | |
| 1 | 123-791H | 3PT 20'-8 SML SDS BOX RH | |
| 1 | 123-790H | 3PT 20'-8 SML SDS BOX LH | |
| 1 | 123-789H | 3PT 20'-7 1/2 SML SDS BOX RH | |
| 1 | 123-788H | 3PT 20'-7 1/2 SML SDS BOX LH | |
| 1 | 123-787H | 3PT 20'-7 SML SDS BOX RH | |
| 1 | 123-785H | 3PT 20'-6 SML SDS BOX RH | |
| 1 | 123-784H | 3PT 20'-6 SML SDS BOX LH | |
| 1 | 123-783H | 3PT 15'-10 SML SDS BOX RH | |
| 1 | 123-782H | 3PT 15'-10 SML SDS BOX LH | |
| 1 | 123-781H | 3PT 15'-8 SML SDS BOX RH | |
| 1 | 123-780H | 3PT 15'-8 SML SDS BOX LH | |
| 1 | 123-779H | 3PT 15'-7 1/2 SML SDS BOX RH | |
| 1 | 123-778H | 3PT 15'-7 1/2 SML SDS BOX LH | |
| 1 | 123-777H | 3PT 15'-7 SML SDS BOX RH | |
| 1 | 123-776H | 3PT 15'-7 SML SDS BOX LH | |
| 1 | 123-774H | 3PT 15'-6 SML SDS BOX LH | |
| 1 | 123-786H | 3PT 20'-7 SML SDS BOX LH | |
| 2 | 803-001C | NUT HEX | |
| 3 | 804-054C | WASHER LOCK#10 | |
| 4 | 804-046C | WASHER FLAT | |
| 5 | 801-003C | SCREW RD HD SLT | |
| 6 | 123-824H | 3PT 12' SML SDS BOX LID | |
| 6 | 123-825H | 3PT 15' SML SDS BOX LID | |
| 6 | 123-826H | 3PT 20' SML SDS BOX LID | |
| 7 | 123-409D | RMVBL SMALL SEED BOX PARTITION | |
| 8 | 816-113C | LATCH KEEPER | |
| 9 | 800-101C | RIVET POP | |
| 10 | 802-078C | HHCS | |
| 11 | 803-007C | NUT-LOCK | |
| 12 | 123-118D | SEED ADJUSTMENT SUPPORT | |
| 13 | 816-112C | RUBBER LATCH | |
| 14 | 123-356D | EWNT SGS LID LATCH | |
| 15 | 838-467C | DECAL SMALL SEEDS DANGER | |
| 16 | 133-147D | SGS UPPER BOX PARTITION | |
| 17 | 804-006C | WASHER LOCK SPRING | |
| 18 | 803-006C | NUT-HEX |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
