Каталог запасных частей к технике: Gaspardo SP DORADA. HYDRAULIC ROW MARKER
1
2
2
3
4
4
5
6
7
8
9
10
10
11
11
11
11
12
12
13
14
14
15
16
17
18
19
20
21
22
22
23
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
39
40
41
42
42
43
44
45
46
47
48
49
49
50
51
52
53
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 15412840 | ATTACK ON DISK | |
| 2 | 13812311 | CHAIN WITH CARABINER | |
| 3 | 15413040 | SLEEVE DISC | |
| 4 | 15410590 | DISC ROW MARKER | |
| 5 | 15412720 | ASS.PROP | |
| 6 | 15412690 | ASS.ARM ROW MARKER LEFT | |
| 7 | 15412680 | ASS.SUPP.ROW MARKER LEFT | |
| 8 | 23440198 | CLASH ATTACK ARM | |
| 9 | 45965010 | SAFETY PLUG D. 8X70 ZN | |
| 10 | 18701600 | WASHER 35,5 X50 X3 ZN | |
| 11 | 43530007 | NUT 10 5588 6.8 ZN | |
| 12 | 45965007 | PLUG, SNAP-ON D 9 B/83 | |
| 13 | 46966131 | PLUG EL.8 X55 DIN 1481 | |
| 14 | 47969001 | GREASE NIPPLE BALL M6X1/A | |
| 15 | 15412810 | ROPE ATTACHMENT LIFT MECC. | |
| 16 | 16240500 | JUMPER ZN | |
| 17 | 23410117 | ELEMENT MOUNTING STEMS | |
| 18 | 15412850 | ASS.SUPP.ROW MARKER RIGHT | |
| 19 | 15412860 | ASS.ARM FOLDED DX | |
| 20 | 15412780 | ASS.EXTENSION ARM SEGNAF. > | |
| 21 | 41602044 | BOLT 10X70 5737 8.G ZN | |
| 22 | 20970024 | WASHER 31,2X2X20,5 | |
| 23 | 20970100 | WASHER 30X0,5X22 | |
| 24 | 22270065 | DUST D. 31 | |
| 25 | 22270385 | KIT-HUBS-AXIS FELT | |
| 26 | 22220150 | DISC ROW MARKER HUB PLASTIC | |
| 27 | 65337004 | SPRING TRAZ.SOLLEV. WAS | |
| 28 | 41605031 | SCREW 8 X25 5739 8.G ZN | |
| 29 | 41605042 | SCREW 10X30 5739 8.G ZN | |
| 30 | 44953003 | WASHER D8 UNI 6592 ZN | |
| 31 | 43530006 | NUT 8 5588 6.8 ZN | |
| 32 | 46966077 | PLUG EL.5 X30 DIN 1481 | |
| 33 | 15410580 | PIVOT DISC ROW MARKER | |
| 34 | 65336135 | SPRING GUIDACORDA D. 45 | |
| 35 | 15470810 | SUPPORT GUIDACORDA | |
| 36 | 15413150 | JUMPER M14X165 - 128 | |
| 37 | 43530009 | NUT 14 5588 6.8 ZN | |
| 38 | 14217330 | THE CYLINDER YOU 30X40 -155 | |
| 39 | 19702710 | DECAL.POSITION CHOKE | |
| 40 | 15413020 | PLUG 15 X120 ZN | |
| 41 | 15413010 | PLUG 15 X62 | |
| 42 | 45961061 | PIN 4 X25 1336 ZN | |
| 43 | 20970142 | WASHER 32X4X15,5 | |
| 44 | 20970111 | WASHER 29,8X2X16,5 | |
| 45 | 13811261 | GLAIVE ROW MARKER | |
| 46 | 15470232 | SUPPORT SPRING 150 | |
| 47 | 18901092 | STEM FERTILIZATION | |
| 48 | 18902861 | REINFORCEMENT SPRING FERTILIZATION | |
| 49 | 41605051 | BOLT 12X35 5739 8.G ZN | |
| 50 | 43530008 | NUT 12 5588 6.8 ZN | |
| 51 | 41602124 | SCREW 14X220 5737 8.G ZN | |
| 52 | 15110091 | CLASH, THE U-SP.8 2F15 165 | |
| 53 | 15211910 | ASS.ARM ROW MARKER LEFT | |
| 54 | 15211930 | ASS.ARM FOLDED DX |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
