Каталог запасных частей к технике: Gaspardo SP DORADA. FRONT DRIVE WHEELS

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
2
3
3
4
4
5
5
5
6
7
8
9
10
10
10
11
11
11
12
13
13
14
15
15
16
16
17
18
18
19
20
21
21
21
21
21
22
22
23
23
24
24
24
24
25
26
27
28
28
28
29
29
29
30
31
31
31
32
32
33
34
34
35
35
35
36
36
36
37
37
37
38
39
40
41
42
43
44
45
45
45
46
47
48
49
49
50
50
50
51
52
53
54
54
55
55
55
56
57
58
59
60
60
61
Позиция на иллюстрации Заводской номер детали Название детали
1 15231320 CARTER LEFT 7.50 (7,50-16)
1 16630360 ASS.CARTER LEFT (5.00-15) - (6.50/80-15)
2 41605041 SCREW 10X25 5739 8.G ZN
3 41605044 SCREW 10 X40 5739 8.G ZN
4 15231440 ATTACK RASCHIATERRA (7,50-16)
4 16630380 CLASH 100X70 -3 4F11 70X40 (5.00-15) - (6.50/80-15)
5 22270280 AXIS A WHEEL NORMAL TRANSMISSION
5 22270281 WHEEL AXLE TRANSMISSION PLUS
5 15231161 ASS.WHEEL AXLE (7,50-16)
6 43530007 NUT 10 5588 6.8 ZN
7 51110008 SUPPORT FY 25 TF
8 52121022 RING ARR.25 UNI 7435-75
9 41607038 SCREW 18X55 MB 5740 8.G ZN
10 10130110 THE WHEEL (5.00-15)
10 56345038 WHEEL 7.50-16 AG 10 (7,50-16)
10 13830630 WHEEL 6.50/80-15 COMPL. (6.50/80-15)
11 15430090 RASCHIATERRA
11 15430660 RASCHIATERRA PLUS
11 15231430 RASCHIAI WHEEL 7,50X16 (7,50-16)
12 44953505 ROND.FLAT 11X30X2,5 6593 ZN
13 43543001 NUT 12X1.5 STUD
13 43543005 NUT 18X1.5 STUD (7,50-16)
14 45965008 SPINAA SHOT D. 4,4 B/80
15 41182016 SCREW 8 X45 5732 4.6 ZN
16 16630310 SUPPORT TRANSMISSION (5.00-15) - (6.50/80-15)
16 15231420 SUPPORT TRANSMISSION (7,50-16)
17 18802610 BUSHING 8,1X14X28 STAINLESS STEEL
18 44953004 WASHER D10 UNI 6592 ZN
19 19005070 GEAR chain TENSIONER Z8
20 44953003 WASHER D8 UNI 6592 ZN
21 43530006 NUT 8 5588 6.8 ZN
22 15231300 CARTER DX 7.50 (7,50-16)
22 16630350 ASS.CARTER DX. (5.00-15) - (6.50/80-15)
23 22505085 AXLE STOP PLATE
24 66248218 SPACER SPREADER
25 41605027 SCREW 8 X16 5739 8.G ZN
26 22220083 RONDELLAAD MOUTH
27 43440005 NUT 8 5448 5.8 ZN
28 14830390 BEARING SQUARE HOLE
29 22230094 BEARING SUPPORT
30 43549002 NUT TRISTOP M 8
31 15231141 WHEEL SUPPORT (7,50-16)
31 16630290 ASS.WHEEL SUPPORT (5,00-15)
31 16630300 ASS.WHEEL SUPPORT (6,50/80-15)
32 15231330 ATT.THE SUPP.WHEEL (7,50-16)
32 16630320 ATTACCOAL SUPPORT WHEEL ZN (5.00-15) - (6.50/80-15)
33 19704700 DECAL.DISP.CHAINS/REF.R.ANT.
34 57159018 SPEZZ.CAT.ISO 10B-1 86 LINKS
34 57159046 'AN.CAT.5/8 94M.ISO 10B-1
35 56243003 COVER 500-15 IM110 4PR
35 56243018 COVER 6.5/80-15 IM 110 4PR
35 COVER 7,50-16 4 P. R. AG 10 (7,50-16)
36 COVER 7,50-16 4 P. R. AG 10 (7,50-16)
36 56244011 ROOM 15 T 340
36 56244003 ROOM 15 L 290
37 56345001 CIRCLE 300 DX15"COL.BEIGE
37 56345016 CIRCLE 5JX15" 4-HOLE CHANNEL
37 COVER 7,50-16 4 P. R. AG 10 (7,50-16)
38 10930061 PINION Z10 5/8 ZN Q. 16,4
39 16630390 PINION Z-15 ZN.
40 16630400 PINION Z-16 ZN.
41 16630410 PINION Z-23 ZN.
42 16630370 GEAR R. the FREE Z-23 ZN
43 16630420 PINION Z-25 ZN.
44 16630430 PINION Z-30 ZN.
45 15470851 SIDE SUPP.BROADCAST SPREADER
46 19002830 TRANSMISSION CRANKCASE UPPER
47 19002880 CARTER INF.BROADCAST SPREADER
48 20890115 CLAMP PLASTIC COMPLETE
49 22250007 GEAR HUB, 1/2-Z-20
50 41605029 SCREW 8 X20 5739 8.G ZN
51 41982002 SCREW 4,2X25 DIN 7981
52 44953500 ROND.FLAT 4.3 X 16X1,5 6593 ZN
53 57158166 AN.CAT 1/2-3/16 66M.ISO 084-1
54 66248207 CHAIN SPREADER
54 22270049 AXIS TRANSMISSION L. 1260
55 20870028 AXIS TRANSMISSION L. 1800
55 22230142 AXIS TRANSMISSION L. 800
55 22230138 AXIS TRANSMISSION L. 1000
56 15272470 PLATE PROL.MEAS.SPAND. (VARIANTS OF THE CHASSIS 150X150)
57 15473080 CARTER REFERRAL FROM ANT.TO POST. (VARIANTS OF THE CHASSIS 150X150)
58 57158048 SP. CAT. 1/2-3/16 74M.ISO 083-1 (VARIANTS CHASSIS 150X150)
59 15110091 CLASH, THE U-SP.8 2F15 165
60 41602124 SCREW 14X220 5737 8.G ZN
60 41601101 SCREW 14X160 5737 8.G ZN
61 43530009 NUT 14 5588 6.8 ZN
