Каталог запасных частей к технике: Gaspardo SP DORADA. COMPLETING ELEMENTS
7
7
8
8
13
14
14
14
15
16
17
18
18
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
51
51
52
52
53
54
54
56
57
58
59
60
61
63
64
65
66
67
67
68
68
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 65337015 | SPRING TRAZ.ZN ADJUSTMENT ITEM | |
| 2 | 18903690 | ATTACK SPRING | |
| 3 | 15422420 | ATTACK SPRING CLOD PUSHER | |
| 4 | 43549002 | NUT TRISTOP M 8 | |
| 5 | 15422400 | AXIS CLOD PUSHER MOBILE | |
| 6 | 15422390 | SUPPORT THE CLOD PUSHER MOBILE | |
| 7 | 45961083 | PIN 5 X30 1336 ZN | |
| 8 | 41605050 | SCREW 12X30 5739 8.G ZN | |
| 9 | 15422410 | FIRM CLOD PUSHER MOBILE | |
| 10 | 18800560 | BUSHING 8,25 X16 X7 | |
| 11 | 44953503 | ROND.FLAT 9X 24X2 6593 ZN | |
| 12 | 41602023 | SCREW 8 X35 5737 8.G ZN | |
| 13 | 15422281 | SUPPORT THE CLOD PUSHER | |
| 14 | 43530007 | NUT 10 5588 6.8 ZN | |
| 15 | 15422211 | SUPPORT RASCHIATERRA DX | |
| 16 | 43442004 | NUT AUTO.NOR.6 ZN | |
| 17 | 19002701 | SECURITY PHOTOCELL | |
| 18 | 18701820 | WASHER 16.5 X 25 X 1 | |
| 19 | 51128011 | BUSHING PAP 15X17X25 | |
| 20 | 15422752 | COVERER DX CORN | |
| 21 | 15421080 | AXIS COVERER ZN | |
| 22 | 15422772 | COVERER LEFT CORN | |
| 23 | 41605020 | SCREW 6 X30 5739 8.G ZN | |
| 24 | 41602038 | SCREW 10X40 5737 8.G ZN | |
| 25 | 18903170 | SPRING TRAZ.ZN RASCHIATERRA | |
| 26 | 41605042 | SCREW 10X30 5739 8.G ZN | |
| 27 | 43530004 | NUT 6 5588 6.8 ZN | |
| 28 | 15422221 | SUPPORT RASCHIATERRA SX | |
| 29 | 15422230 | RASCHIATERRA DISK | |
| 30 | 15423400 | SPACER | |
| 31 | 44953502 | ROND.FLAT 6.6 X 18X2 6593 ZN | |
| 32 | 41605015 | SCREW 6 X16 5739 8.G ZN | |
| 33 | 43533021 | NUT M16X1,5 5589 6.8 ZN | |
| 34 | 15422361 | SUPPORT DISC | |
| 35 | 15220540 | NUT M16X1,5 LH | |
| 36 | 43549003 | NUT TRISTOP M10 | |
| 37 | 44957007 | WASHER D10 DIN 6798 D. INT.ZN | |
| 38 | 15420713 | SUPPORT FALCIONE CORN | |
| 39 | 18902481 | MOLLAAGGANCIO FALCIONE | |
| 40 | 22270428 | HOOK FALCIONE | |
| 41 | 22270397 | SHARP GLAIVE CORN | |
| 42 | 41605041 | SCREW 10X25 5739 8.G ZN | |
| 43 | 15423390 | EXTENSION FALCIONE | |
| 44 | 22505131 | DISC COULTER COMPLETE | |
| 45 | 15420852 | SPIANATERRA | |
| 46 | 16620231 | MONT. GLAIVE SOWING DEEP | |
| 47 | 52122038 | RING ARR.47 UNI 7437-75 | |
| 48 | 66248248 | PLASTIC CAP | |
| 49 | 15223651 | BEARING SUPPORT DISK | |
| 50 | 51180002 | BEARING 3303 2RS | |
| 51 | 13825091 | DISC COULTER D. 373 | |
| 52 | 22310058 | BUSHING DUST BOOT DISK | |
| 53 | 15421761 | INNER FLANGE DISC | |
| 54 | 48974019 | RIVET TSC 6 X19,8 3012690 | |
| 55 | 41605044 | SCREW 10 X40 5739 8.G ZN | |
| 56 | 15420734 | GLAIVE CORN | |
| 57 | 15225240 | EXTRACTOR DISCS | |
| 58 | 16620240 | ASS.SUPP. GLAIVE PEANUTS | |
| 59 | 16620260 | MONT.GLAIVE PEANUT SP540 | |
| 60 | 16620181 | ASS.SUPP.GLAIVE SOWING PROF. | |
| 61 | 16620220 | CUTTING HOOK SEM.DEEP | |
| 62 | 15225480 | FLANGE INT DISK PROTTETTO ZN | |
| 63 | 53229008 | SEAL RING G24X32X4 | |
| 64 | 15225490 | BUSHING PARAP.THE PROTECTED DISK | |
| 65 | 15223651 | SUPP.BEARING ZN | |
| 66 | 15225500 | MONT.DISK ASSOLCAI PROTECTED | |
| 67 | 43533006 | NUT 10 5589 6.8 ZN | |
| 68 | 41605043 | BOLT 10X35 5739 8.G ZN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
