Каталог запасных частей к технике: Gaspardo Сеялка OLIMPIA, ORIETTA-C. FERTILIZER TRANSMISSION AND MICROGRANULATOR
1
1
1
1
1
2
3
3
4
5
6
7
7
8
9
10
11
12
13
14
14
14
14
15
16
17
18
18
18
18
18
19
19
19
19
20
20
21
22
23
24
25
26
27
27
28
29
29
29
30
31
31
31
32
32
32
32
32
32
33
34
35
35
36
37
38
39
40
41
42
43
44
45
45
45
45
45
46
46
46
47
48
49
50
51
52
53
54
55
56
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | G14830390 | SQUARE-HOLED BEARING | |
| 2 | F06080024 | Cut-down chain. | |
| 3 | G15470851 | SPREADER TRANSM. SIDE SUPPORT | |
| 4 | G15475031 | LEFT TRANSMISSION SUPPORT | |
| 5 | G15475041 | RIGHT TRANSMISSION SUPPORT | |
| 6 | G15475260 | STRIKER PLATE SP | |
| 7 | G15475310 | MICRO CHAIN STRETCHER ROLLERS | |
| 8 | G18902960 | TRANSMISSION TENSIONER SPRING | |
| 9 | G19000091 | CHAIN TENSIONER | |
| 10 | G19002810 | RIGHT MICRO TRANSM. CASE | |
| 11 | G19002820 | LEFT MICRO TRANSM. CASE | |
| 12 | G19002830 | TOP TRANSMISSION CASE | |
| 13 | G19002880 | BOTTOM SPREADER TRANSM. CASE | |
| 14 | G22505085 | PLATE AXLE STOP | |
| 15 | G20890128 | RING GEAR Z-42 SP | |
| 16 | G20970032 | WASHER 32X4X8-5 | |
| 17 | G20980086 | BUSHING SPAC.. D.8-5X16X31 | |
| 18 | G22230094 | BEARING SUPPORT | |
| 19 | G20910039 | INGRANAGGIO SUP.Z-20 FERRO | |
| 20 | G22250006 | Gears | |
| 21 | F20110706 | DISK SUPPORT.ELEMENT U BOLT SV | |
| 22 | G22270127 | Wheel axle - gearbox 2-row l. | |
| 23 | F01060047 | BOLT 8X45 5732 4.6 GALVANIZED | |
| 24 | F01020075 | BOLT 8X55 5737 8.8 GALVANIZED | |
| 25 | F01020083 | BOLT M8X70 | |
| 26 | F01020225 | SCREW M14X160 5737 8.G | |
| 27 | F01020403 | SCREW M6X1X16 U5739 8.8 ZN | |
| 28 | G15875320 | Intermediate case | |
| 29 | F01020436 | SCREW M8X1,25X20 U5739 8.8 ZN | |
| 30 | F01070074 | BOLT 4-2X25 DIN 7981 | |
| 31 | F01200232 | DADO M6X1 U5588 6.8 ZN | |
| 32 | F01200244 | NUT M8X1,25 U5588 6.8 ZN | |
| 33 | F01200270 | NUT M10X1,5 U5588 6.8 ZN | |
| 34 | F01410037 | PLANE WASHER D.6 | |
| 35 | F01410051 | WASHER M8 8,4X17X1,6 U6592 ZN | |
| 36 | F01410064 | WASHER M10 10,5X20X2 U6592 ZN | |
| 37 | F01420011 | FLAT WASHER 4-3X16X1-5 6593 G | |
| 38 | F01430047 | WASHER D6 DIN 6798 D.INT.GALV. | |
| 39 | G15875310 | Transmission drive ass. | |
| 40 | F01100011 | GREASE NIPPLE M6X1 7663-A ZN | |
| 41 | F06080056 | Sp.cat. | |
| 42 | F06080025 | Chain | |
| 43 | G66248152 | HUB - TRANSM. MICRO M80 | |
| 44 | G66248207 | CHAIN TENSIONER | |
| 45 | G66248218 | MAN. SPR. SPACER WASHER | |
| 46 | F01420048 | WASHER M8 8,4X24X2 U6593 ZN | |
| 47 | F02200452 | SNAP PIN D4,4 B/80 ZN | |
| 48 | G10538351 | Square hole bearing | |
| 49 | F01070073 | Bolt | |
| 50 | G15110091 | STRIKER | |
| 51 | F01200306 | NUT M14X2 | |
| 52 | F01200244 | NUT M8X1,25 U5588 6.8 ZN | |
| 53 | F01020432 | BOLT M8X16 | |
| 54 | G15870380 | Transmission axle | |
| 55 | G22230142 | 4-ROW SPINDLE L.800 | |
| 56 | G20970142 | WASHER 32X4X15-5 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
