Каталог запасных частей к технике: Gaspardo Сеялка OLIMPIA, ORIETTA-C. ELEMENT FRAME

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
4
5
6
6
6
7
8
9
9
9
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
25
26
26
27
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
49
50
50
51
51
52
53
54
55
55
56
56
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
Позиция на иллюстрации Заводской номер детали Название детали
1 F01020170 SCREW M12X1,75X100 5737 8.8 ZN
2 G66349003 BUSHING- SINTERED
3 G22250405 Pin- lower arm
4 G15828250 Frame coupling
5 G15827900 Braccio sup.parallelogramma
6 F01220048 NUT M12X1,75 D980 8 ZN
7 F01020432 BOLT M8X16
8 G14820991 Adjustment stop
9 F01200244 NUT M8X1,25 U5588 6.8 ZN
10 G19003400 Depth indicating rod
11 F02200363 SPLIT PIN R 3X62
12 G18903140 PIPE GUIDE SUPPORT
13 G15827930 Carter ant.
14 G65336100 Spec spring handle stop sp
15 F06080223 Sp.cat.
16 G15881270 Carter laterale
17 F01070011 BOLT- SELF-TAPPING 4-2X9-5T.E.
18 F01020440 BOLT M8X1,25X25 U5739 8.8 ZN
19 F01420048 WASHER M8 8,4X24X2 U6593 ZN
20 G20980050 BUSHING 15X7X8-5 ZN
21 F01200306 NUT M14X2
22 F02250077 Aluminium pull rivet
23 G65337035 Molla tendicatena ruota dp
24 F02200165 Split pin
25 F01030056 Bolt
26 G15821110 Seed cover supp. Bushing
27 G16610010 Winged screw
28 G15829970 Attacco dx molla copriseme
29 G15829820 Braccio bilanciere
30 F01200270 NUT M10X1,5 U5588 6.8 ZN
31 G19006460 Distanziale
32 F01020472 BOLT 10X25 5739 8.G GALVANIZED
33 G15881090 Copriseme dx
34 F01200232 DADO M6X1 U5588 6.8 ZN
35 G19005300 Distanziale
36 G15881080 Copriseme sx
37 G15829960 Attacco sx molla copriseme
38 G15110091 STRIKER
39 G19005110 Rullo tendicatena
40 G18902520 Molla traz.zn raschiaterra
41 F01020403 SCREW M6X1X16 U5739 8.8 ZN
42 G18801450 Bushing
43 G15829790 Ass.telaietto seminatore
44 F01230034 SELF LOCK.NUT M8X1,25 D982 8ZN
45 F02050615 STOP RING 28 UNI 7435-75
46 F06220010 8-lobe handwheel
47 G22230063 ARTICULATED ELEMENT
48 G22230062 Adjustment bolt
49 F01410088 WAS.M14 15X28X2,5 U6592 ZB
50 F02100109 PIN EL. .6X24 DIN 1481
51 G22270235 ADJUSTMENT HANDLE B4
52 G15827940 Braccetto inf.
53 G15829681 Asta aggancio
54 G18902880 Parallel stop spring sp
55 G20980082 Bushing
56 G20970035 WASHER 32X4X13
57 F01020174 Bolt
58 G15881320 Braccio tendicatena
59 F01020528 SCREW M12X1,75X40 U5739 10.9ZN
60 G22250190 PLANTING UNIT AXLE Z-15 RING G
61 G15725030 Bearing support
62 G22250441 PLANTING UNIT CROWN HUB SV/2
63 F04010135 Bearing
64 F02050101 SEEGER RING E. 25X1,2 7435 C70
65 G15828660 Lightening spring coupling
66 G15829290 Indice molla parallelogr. Zn
67 G15220120 Regulation bolt
68 G15828760 Bushing- tightener
69 G22505063 Bolt- rear wheel adjustm.
70 G22505061 Bushing
71 F01030060 Bolt
72 G15829851 Copriseme regolabile sx
73 G15829861 Copriseme regolabile dx
74 F01060040 SCREW M8X1,25X20 U5732 4.6 ZN
75 G15882440 Supp.dx copriseme regolabile
76 G15882450 Supp.sx copriseme regolabile
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
